Fujitsu ASU9RLS2 User Manual

- (01 - 09) -
WALL MOUNTED TYPE ASU9-15RLS2 WALL MOUNTED TYPE ASU9-15RLS2
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL

: ASU9RLS2
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
SHC : Sensible Heat Capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
MODEL

: ASU12RLS2
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
SHC : Sensible Heat Capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
AFR 500
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
67 8.4 6.0 0.38 9.4 6.0 0.39 10.3 6.6 0.40 10.7 7.1 0.40 11.3 7.1 0.40 11.9 7.5 0.41
77 8.0 5.7 0.44 8.9 5.7 0.44 9.8 6.2 0.45 10.2 6.7 0.45 10.8 6.7 0.46 11.4 7.2 0.46
87 7.6 5.4 0.49 8.4 5.4 0.49 9.3 5.9 0.50 9.6 6.4 0.50 10.2 6.4 0.51 10.8 6.8 0.51
95 7.1 5.1 0.54 7.9 5.1 0.55 8.7 5.6 0.56 9.0 6.0 0.56 9.5 6.0 0.57 10.1 6.4 0.57
104 6.0 4.5 0.50 6.7 4.5 0.51 7.4 4.9 0.52 7.6 5.3 0.52 8.1 5.3 0.53 8.5 5.7 0.53
115 5.5 4.2 0.50 6.2 4.2 0.51 6.8 4.6 0.52 7.0 5.0 0.52 7.4 4.9 0.53 7.8 5.3 0.53
AFR 14.2
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
19.4 2.47 1.76 0.38 2.75 1.77 0.39 3.03 1.93 0.40 3.13 2.08 0.40 3.31 2.07 0.40 3.50 2.21 0.41
25.0 2.35 1.67 0.44 2.62 1.68 0.44 2.89 1.83 0.45 2.98 1.98 0.45 3.15 1.97 0.46 3.33 2.10 0.46
30.6 2.22 1.58 0.49 2.48 1.59 0.49 2.73 1.73 0.50 2.81 1.87 0.50 2.98 1.86 0.51 3.15 1.98 0.51
35.0 2.08 1.48 0.54 2.32 1.49 0.55 2.56 1.63 0.56 2.64 1.76 0.56 2.80 1.75 0.57 2.95 1.86 0.57
40.0 1.76 1.32 0.50 1.96 1.33 0.51 2.16 1.45 0.52 2.23 1.57 0.52 2.36 1.56 0.53 2.50 1.66 0.53
46.0 1.62 1.23 0.50 1.81 1.23 0.51 1.99 1.35 0.52 2.05 1.45 0.52 2.18 1.45 0.53 2.30 1.54 0.53
AFR 500
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
67 11.2 7.8 0.60 12.5 7.9 0.61 13.8 8.6 0.61 14.2 9.3 0.62 15.1 9.3 0.62 15.9 9.9 0.63
77 10.7 7.4 0.68 11.9 7.5 0.69 13.1 8.2 0.70 13.5 8.8 0.70 14.3 8.8 0.71 15.2 9.4 0.72
87 10.1 7.0 0.76 11.3 7.1 0.77 12.4 7.7 0.78 12.8 8.3 0.78 13.6 8.3 0.79 14.3 8.9 0.80
95 9.5 6.6 0.84 10.6 6.7 0.85 11.6 7.3 0.87 12.0 7.8 0.87 12.7 7.8 0.88 13.4 8.3 0.89
104 8.0 5.9 0.78 8.9 5.9 0.79 9.8 6.5 0.80 10.1 7.0 0.81 10.8 7.0 0.82 11.4 7.4 0.83
115 7.4 5.5 0.78 8.2 5.5 0.79 9.1 6.0 0.81 9.3 6.5 0.81 9.9 6.5 0.82 10.5 6.9 0.83
AFR 14.2
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
19.4 3.29 2.30 0.60 3.67 2.31 0.61 4.04 2.52 0.61 4.17 2.72 0.62 4.42 2.71 0.62 4.67 2.89 0.63
25.0 3.13 2.18 0.68 3.49 2.20 0.69 3.85 2.39 0.70 3.97 2.59 0.70 4.20 2.58 0.71 4.44 2.74 0.72
30.6 2.96 2.06 0.76 3.30 2.08 0.77 3.64 2.26 0.78 3.75 2.44 0.78 3.98 2.44 0.79 4.20 2.59 0.80
35.0 2.78 1.94 0.84 3.09 1.95 0.85 3.41 2.13 0.87 3.52 2.30 0.87 3.73 2.29 0.88 3.94 2.44 0.89
40.0 2.35 1.73 0.78 2.62 1.74 0.79 2.88 1.90 0.80 2.97 2.05 0.81 3.15 2.04 0.82 3.33 2.17 0.83
46.0 2.16 1.60 0.78 2.41 1.61 0.79 2.66 1.76 0.81 2.74 1.90 0.81 2.90 1.89 0.82 3.07 2.02 0.83
