WALL MOUNTED TYPE ASU9-15RLS2 WALL MOUNTED TYPE ASU9-15RLS2
MODEL

: ASU15RLS2
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
IP : Input Power (kW)
AFR 559
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
-5 -7 17.6 2.11 17.1 2.16 16.7 2.20 15.9 2.29
5 3 19.3 2.14 18.9 2.19 18.4 2.23 17.5 2.32
14 12 20.7 2.18 20.2 2.23 19.7 2.27 18.7 2.36
23 19 21.6 2.28 21.1 2.33 20.5 2.38 19.5 2.48
32 28 21.8 2.48 21.3 2.53 20.7 2.58 19.7 2.68
41 37 23.8 2.32 23.2 2.37 22.7 2.42 21.5 2.52
47 43 25.1 2.17 24.5 2.21 23.9 2.26 22.7 2.35
50 47 27.7 1.94 27.1 1.98 26.4 2.02 25.1 2.10
59 50 28.7 1.95 28.0 1.99 27.4 2.03 26.0 2.11
AFR 15.8
Indoor temperature
°CDB 16 18 20 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-20.6 -21.7 5.15 2.11 5.02 2.16 4.90 2.20 4.66 2.29
-15.0 -16.1 5.67 2.14 5.54 2.19 5.40 2.23 5.13 2.32
-10.0 -11.1 6.06 2.18 5.92 2.23 5.78 2.27 5.49 2.36
-5.0 -7.2 6.32 2.28 6.17 2.33 6.02 2.38 5.72 2.48
0.0 -2.2 6.38 2.48 6.23 2.53 6.08 2.58 5.77 2.68
5.0 2.8 6.97 2.32 6.81 2.37 6.64 2.42 6.31 2.52
8.3 6.1 7.35 2.17 7.18 2.21 7.00 2.26 6.65 2.35
10.0 8.3 8.12 1.94 7.93 1.98 7.74 2.02 7.35 2.10
15.0 10.0 8.42 1.95 8.22 1.99 8.02 2.03 7.62 2.11
