Item no. Part no. Part name Service part
1 9322556028 Top panel assy ♦
2 9377840004 Protective net ♦
3 9322552259 Cabinet right assy ♦
4 9384268006 Conduit cover ♦
5 9322570055 Switch cover assy ♦
6 9322138002 Thermistor holder ♦
7
9709684030 Main PCB (For 09 model) ♦
9709684047 Main PCB (For 12 model) ♦
8 9900565060 Thermistor assy ♦
9 9900727062 Thermistor assy ♦
10 9900583019 Reactor assy ♦
11 9322418005 Heat sink ♦
12 9383720000 Drain cap assy ♦
13 9323550025 Base assy ♦
14 9322144003 Drain pipe ♦
15 9317903011 Emblem ♦
16 9384265005 Fan guard ♦
17 9322555199 Front panel assy ♦
18 9322136008 Propeller fan ♦
19 9603657017 Brushless motor ♦
20 9322553010 Motor bracket assy ♦
21
9322274021 Condenser total assy (For 09 model) ♦
9322275004 Condenser total assy (For 12 model) ♦
a — Inverter assy
b — Hair pin cushion
3-1. Models: AOUG09LMAS1 and AOUG12LMAS1 - (02-7) - 3. Outdoor unit parts list
