Model: AOUG12LMAS1
Fan speed is defined by outdoor temperature and compressor frequency.
• Outside air temperature zone selection
21°C
Outside air
temperature rises
Z zone
Y zone
F zone
G zone
Outside air
temperature drops
12°C
2°C
19°C
10°C
0°C
Unit: rpm
Fan step
Cooling
Heating
Dry Cooling or dry
Y zone Y zone Z zone F zone G zone
S-HIGH2 — 1,120 — — — —
S-HIGH1 990 1,120 — — — —
HIGH1 990 1,120 — — — —
10 — 1,120 — — — —
9 990 1,120 990 390 320 240
8 940 1,120 940 390 320 240
7 940 940 940 390 320 240
6 940 780 940 300 240 200
5 890 690 890 250 240 200
4 790 630 790 250 240 200
3 710 570 710 250 240 200
2 660 570 660 250 240 200
1 620 570 620 250 240 200
NOTE: After defrost control on the heating mode, the fan speed is kept higher regardless of the
compressor frequency.
Fan speed after defrost control: 1,120 rpm
