En-9
5.1. Function details
■
Filter sign
Select appropriate intervals for displaying the fi lter sign on the indoor unit according to the
estimated amount of dust in the air of the room.
If the indication is not required, select “No indication” (03).
(♦... Factory setting)
Function
number
Setting
value
Setting description
11
00 Standard (400 hours)
01 Long interval (1000 hours)
02 Short interval (200 hours)
03 No indication ♦
■
Auto restart
Enable or disable automatic restart after a power interruption.
(♦... Factory setting)
Function
number
Setting
value
Setting description
40
00 Enable ♦
01 Disable
* Auto restart is an emergency function such as for power outage etc. Do not attempt to
use this function in normal operation. Be sure to operate the unit by remote controller or
external device.
■
Room temperature sensor switching
(Only for wired remote controller)
When using the Wired remote controller temperature sensor, change the setting to “Both” (01).
(♦... Factory setting)
Function
number
Setting
value
Setting description
42
00 Indoor unit ♦
01 Both
00: Sensor on the indoor unit is active.
01: Sensors on both indoor unit and wired remote controller are active.
*
Remote controller sensor must be turned on by using the remote controller
■
Remote controller custom code
(Only for wireless remote controller)
The indoor unit custom code can be changed. Select the appropriate custom code.
(♦... Factory setting)
Function
number
Setting
value
Setting description
44
00 A ♦
01 B
02 C
03 D
■
External input control
“Operation/Stop” mode or “Forced stop” mode can be selected.
(♦... Factory setting)
Function
number
Setting
value
Setting description
46
00 Operation/Stop mode 1 (R.C. enabled) ♦
01 (Setting prohibited)
02 Forced stop mode
03 Operation/Stop mode 2 (R.C. disabled)
■
Room temperature sensor switching (Aux.)
To use the temperature sensor on the wired remote controller only, change the setting to “Wired
remote controller” (01). This function will only work if the function setting 42 is set at “Both” (01)
(♦... Factory setting)
Function
number
Setting
value
Setting description
48
00 Both ♦
01 Wired remote controller
■
Indoor unit fan control for energy saving for cooling
Enables or disables the power-saving function by controlling the indoor unit fan rotation when
the outdoor unit is stopped during cooling operation.
(♦... Factory setting)
Function
number
Setting
value
Setting description
49
00 Disable
01 Enable
02 Remote controller ♦
00: When the outdoor unit is stopped, the indoor unit fan operates continuously following
the setting on the remote controller.
01: When the outdoor unit is stopped, the indoor unit fan operates intermittently at a very
low speed.
02: Enable or disable this function by remote controller setting.
*When using a wired remote controller without Indoor unit fan control for energy saving for
cooling function, or when connecting a single split converter, the setting cannot be made
by using the remote controller. Set to (00) or (01).
To confi rm if the remote controller has this function, refer to the operating manual of each
remote controller.
■
Setting record
Record any changes to the settings in the following table.
Function
number
Setting description Setting value
11 Filter sign
40 Auto restart
42 Room temperature sensor switching
44 Remote controller custom code
46
External input control
The rotary switch on the “External input and output PCB”
48 Room temperature sensor switching (Aux.)
49 Indoor unit fan control for energy saving for cooling
After completing the Function Setting, be sure to disconnect the power supply and then recon-
nect it.
5.2. Temperature correction
NOTES:
When changing Function 95, perform this setting before other Room temp. control settings
(Function 30, 31, 35, 36).
If Function 95 is not set fi rst, Room temperature control settings (Function 30, 31, 35, 36)
will be reset and you must re-do them again.
■
Heat Insulation condition (building insulation)
Heat insulation conditions differ according to the installed environment.
“Standard insulation” (00) allows system to rapidly respond to the cooling or heating load
changes.
“High insulation” (01) is when the heat insulation structure of the building is high and does
not require system to rapidly respond to cooling or heating load changes.
When “High insulation” (01) is selected;
• Overheating (overcooling) is prevented at the start-up.
• All room temp. control settings (Function 30, 31, 35, 36) will reset to “No correction” [0.0°F
(0.0°C)].
(♦... Factory setting)
Function
number
Setting
value
Setting description
95
00 Standard insulation ♦
01 High insulation
9387603095_IM.indb 99387603095_IM.indb 9 2019/11/18 15:54:552019/11/18 15:54:55
