Installation space requirement
Provide sufficient installation space for product safety.
Unit: in (mm)
Wall hook bracket
Outline of the indoor unit
2 (50) or more
3 (71) or more
2(40) or more
3 (70) or more
5 (117) or more
60 (1,500) or more
71 (1,800) or more
7 (160) or more
2-1. Indoor unit - (01-5) - 2. Dimensions
