Item no. Part no. Part name Service part

1 9323351004 Bracket panel ♦

2 9387476002 Screw cap ♦

3 9313951047 Conduit holder ♦

4 9387597035 Wire cover assy ♦

5 9383765032 Wifi holder assy ♦

6 9383634017 Wireless LAN adapter ♦

7 9387479010 U/D louver assy ♦

8 9332911008 Electric filter holder ♦

9 9323341005 Under cover L ♦

10 9317250009 Air clean filter assy ♦

11 9332438765 Remote controller ♦

12 9318912005 Remote controller holder ♦

13 9387596441 Front panel total assy ♦

14 9387756210 Intake grille assy ♦

15 9323340008 Air filter ♦

16 9333719009 Grille clamper L ♦

17 9333704005 Grille clamper R ♦

18 9323342002 Under cover R ♦

19 9383730023 Louver spring ♦

20 9333608006 Bush ♦

a — Front panel —

b — Panel cover —

c — Front panel cover —

d — Front panel B —

2-1. Models: ASUG09LZAS, ASUG12LZAS, and ASUG15LZAS - (02-3) - 2. Indoor unit parts list
