Item no. Part no. Part name Service part
50
9810542007 Compressor (for 09-12 model) ♦
9810541000 Compressor (for 15 model) ♦
51 9322446015 4-way valve assy ♦
52 9970194023 Solenoid ♦
53 9970173028 Expansion valve coil ♦
54 9322463029 Pulse motor valve assy ♦
55 9322474001 2-way valve assy ♦
56
9322850010 3-way valve assy (for 09-12 model) ♦
9387831016 3-way valve assy (for 15 model) ♦
57 9322824004 S-insulator K ♦
58 9323045002 S-insulator V ♦
59 9322501004 S-insulator H ♦
60 9322847003 S-insulator F ♦
61 9322503008 S-insulator B ♦
a — Valve bracket —
b — Muffler —
3-1. Models: AOUG09LZAS1, AOUG12LZAS1, and AOUG15LZAS1 - (02-9) - 3. Outdoor unit parts list
