3. Dimensions
3-1. Models: ASUG09LZAS, ASUG12LZAS, and ASUG15LZAS
Unit: in (mm)
38-9/16 (980) 9-7/16 (240)
11 (280)
Outline of indoor unit
1-7/16 (37) 1-7/16 (37)
15-3/4 (400) 3-9/16
(90)
16-1/4 (413)3-1/16
(77)
2-7/8
(73)
16-7/16 (417)2-3/8
(61)
16-7/8 (429)
4-1/2 (115)
2-13/16 (72)
for pipe inlet
Ø 2-9/16 (65)
for pipe inlet
Ø 2-9/16 (65)
- 6 -
3-1. Models: ASUG09LZAS, ASUG12LZAS, and ASUG15LZAS 3. Dimensions
WALL MOUNTED ASUG09-15LZAS WALL MOUNTED ASUG09-15LZAS
