Fujitsu ASUH18LMAS Design & Technical Manual

¢
Model: ASUH24LMAS
AFR CFM 647
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW
14 19.67 10.96 0.94 21.52 12.00 0.95 23.58 13.15 0.97 24.31 13.55 0.98 25.91 14.44 0.99 27.62 15.39 1.00
23 17.85 10.16 1.25 19.54 11.12 1.26 21.41 12.18 1.29 22.07 12.56 1.30 23.52 13.38 1.32 25.07 14.27 1.33
32 16.94 9.82 1.39 18.54 10.75 1.40 20.32 11.78 1.43 20.94 12.14 1.44 22.32 12.94 1.46 23.79 13.80 1.47
41 18.12 10.09 1.31 19.83 11.04 1.33 21.73 12.10 1.36 22.40 12.48 1.37 23.87 13.29 1.38 25.44 14.17 1.40
50 19.13 10.93 1.24 20.93 11.96 1.25 22.94 13.11 1.28 23.64 13.51 1.29 25.20 14.40 1.31 26.86 15.35 1.32
59 20.18 11.48 1.10 22.08 12.56 1.11 24.20 13.76 1.13 24.94 14.19 1.14 26.58 15.12 1.15 28.34 16.11 1.17
67 20.40 11.79 1.05 22.32 12.90 1.07 24.46 14.14 1.09 25.22 14.58 1.10 26.87 15.53 1.11 28.65 16.56 1.12
77 19.79 11.11 1.36 21.66 12.16 1.38 23.73 13.33 1.41 24.46 13.74 1.42 26.07 14.64 1.43 27.79 15.61 1.45
87 18.85 10.78 1.52 20.63 11.80 1.53 22.60 12.93 1.56 23.30 13.33 1.58 24.83 14.20 1.60 26.47 15.14 1.61
95 17.80 10.42 1.69 19.47 11.40 1.71 21.34 12.49 1.74 22.00 12.88 1.76 23.44 13.72 1.78 24.99 14.63 1.80
104 16.64 10.06 1.85 18.21 11.01 1.87 19.95 12.07 1.91 20.57 12.44 1.93 21.92 13.25 1.95 23.37 14.13 1.97
115 12.66 8.85 1.55 13.85 9.68 1.56 15.18 10.61 1.59 15.65 10.93 1.61 16.68 11.65 1.63 17.78 12.42 1.64
AFR
m
3
/h
1,100
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 5.76 3.21 0.94 6.31 3.52 0.95 6.91 3.85 0.97 7.13 3.97 0.98 7.59 4.23 0.99 8.09 4.51 1.00
-5.0 5.23 2.98 1.25 5.73 3.26 1.26 6.27 3.57 1.29 6.47 3.68 1.30 6.89 3.92 1.32 7.35 4.18 1.33
0.0 4.97 2.88 1.39 5.43 3.15 1.40 5.95 3.45 1.43 6.14 3.56 1.44 6.54 3.79 1.46 6.97 4.04 1.47
5.0 5.31 2.96 1.31 5.81 3.24 1.33 6.37 3.55 1.36 6.56 3.66 1.37 6.99 3.90 1.38 7.46 4.15 1.40
10.0 5.61 3.20 1.24 6.13 3.50 1.25 6.72 3.84 1.28 6.93 3.96 1.29 7.38 4.22 1.31 7.87 4.50 1.32
15.0 5.91 3.36 1.10 6.47 3.68 1.11 7.09 4.03 1.13 7.31 4.16 1.14 7.79 4.43 1.15 8.30 4.72 1.17
19.4 5.98 3.46 1.05 6.54 3.78 1.07 7.17 4.14 1.09 7.39 4.27 1.10 7.88 4.55 1.11 8.40 4.85 1.12
25.0 5.80 3.26 1.36 6.35 3.56 1.38 6.96 3.91 1.41 7.17 4.03 1.42 7.64 4.29 1.43 8.15 4.57 1.45
30.6 5.52 3.16 1.52 6.05 3.46 1.53 6.63 3.79 1.56 6.83 3.91 1.58 7.28 4.16 1.60 7.76 4.44 1.61
35.0 5.22 3.05 1.69 5.71 3.34 1.71 6.26 3.66 1.74 6.45 3.77 1.76 6.87 4.02 1.78 7.32 4.29 1.80
40.0 4.88 2.95 1.85 5.34 3.23 1.87 5.85 3.54 1.91 6.03 3.65 1.93 6.42 3.88 1.95 6.85 4.14 1.97
46.1 3.71 2.59 1.55 4.06 2.84 1.56 4.45 3.11 1.59 4.59 3.20 1.61 4.89 3.42 1.63 5.21 3.64 1.64
- 10 -
4-1. Cooling capacity
4. Capacity table
WALL MOUNTED ASUH18-24LMAS WALL MOUNTED ASUH18-24LMAS
