Fujitsu ASUH18LMAS Design & Technical Manual

1. Specifications
Type
Wall mounted
Inverter heat pump
Model name ASUH18LMAS ASUH24LMAS
Power supply 208/230 V ~ 60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
Rated
kW 5.28 6.45
Btu/h 18,000 22,000
Min.—Max.
kW 2.05—5.86 2.67—8.00
Btu/h 7,000—20,000 9,100—27,300
Heating
Rated
kW 6.33 7.39
Btu/h 21,600 25,200
Min.—Max.
kW 2.34—8.50 2.40—10.84
Btu/h 8,000—29,000 8,200—37,000
Heating
(17°F)
*1
Rated
kW 3.99 4.60
Btu/h 13,600 15,700
Max.
kW 6.95 8.41
Btu/h 23,700 28,700
Input power
Cooling
Rated
kW
1.38 1.76
Min.—Max. 0.45—1.86 0.43—2.63
Heating
Rated 1.58 1.87
Min.—Max. 0.55—2.82 0.52—3.53
Heating
(17°F)
*1
Rated 1.28 1.51
Max. 0.41—3.06 0.39—3.60
Current
Cooling
Rated A
6.2 7.8
Heating 7.0 8.3
EER Cooling
kW/kW 3.80 3.66
Btu/hW 13.0 12.5
COP Heating
kW/kW 4.00 3.95
Btu/hW 13.6 13.5
SEER Cooling Btu/hW 21.1 22.5
HSPF Heating Btu/hW 12.5 12.0
Power factor
Cooling
%
96.8 98.1
Heating 98.1 98.0
Moisture removal pints/h (L/h) 4.0 (1.9) 6.3 (3.0)
Maximum operating current*
2
Cooling
A
13.4 15.4
Heating 13.9 15.9
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
577 (980) 647 (1,100)
MED 489 (830) 530 (900)
LOW 377 (640) 436 (740)
QUIET 300 (510) 371 (630)
Heating
HIGH 589 (1,000) 730 (1,240)
MED 500 (850) 530 (900)
LOW 377 (640) 436 (740)
QUIET 300 (510) 371 (630)
Type × Q'ty Crossflow fan × 1
Motor output W 59 78
Sound pressure level*
3
Cooling
HIGH
dB (A)
46 46
MED 41 42
LOW 35 37
QUIET 30 33
Heating
HIGH 46 48
MED 41 38
LOW 35 34
QUIET 30 30
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main 1: 8-1/4 × 31-5/16 × 1-1/16
(210 × 796 × 26.6)
Main 2: 4-15/16 × 31-5/16 × 1-1/16
(126 × 796 × 26.6)
Sub 1: 3-5/16 × 31-5/16 × 1/2
(84 × 796 × 13.3)
18-3/16 × 35-6/16 × 1-1/16
(462 × 898 × 26.6)
Fin pitch FPI (mm)
Main 1: 21 (1.2)
Main 2: 21 (1.2)
Sub 1: 18 (1.4)
21 (1.2)
Rows × Stages
Main 1: 2 × 10
Main 2: 2 × 6
Sub 1: 1 × 4
2 × 22
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in (mm)
11 × 38-9/16 × 9-7/16
(280 × 980 × 240)
13-6/16 × 45-4/16 × 11
(340 × 1,150 × 280)
Gross
12-11/16 × 42-7/16 × 13-5/8
(322 × 1,078 × 346)
15-15/16 × 50 × 17-11/16
(405 × 1,270 × 450)
Weight
Net
lb (kg)
29 (13.0) 36 (16.5)
Gross 36 (16.5) 49 (22.0)
Connection pipe
Size
Liquid
in (mm)
Ø3/8 (Ø9.52)
Gas Ø5/8 (Ø15.88)
Method Flare
Drain hose
Material PP+HDPE
Tip diameter in (mm)
Ø17/32 (Ø13.8) (I.D.),
Ø19/32 to 21/32 (Ø15.0 to 16.8) (O.D.)
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 86 (30) or less
Remote controller type
Wireless (Wired, Mobile app*
4
[FGLair
™
] [option])
- 2 -
1. Specifications
