6. COMPRESSOR CONTROL
1. OPERATION FREQUENCY RANGE
The operation frequency of the compressor is different based on the operation mode as
shown in the table 4.
Cooling Heating
Min Max Min Max
18Hz 80Hz 18Hz 110HzAOYA14LAC2
(Table 4 : Compressor Operation Frequency Range)
2. OPERATION FREQUENCY CONTROL AT START UP
01-07
The compressor frequency soon after the start-up is controlled as shown in Figure 10.
(Fig.10 : Compressor Control at Start-up)
40Hz
120sec
120sec
60- 720sec
180- 720sec 300- 720sec
56Hz
82Hz
To Next Page
