14-9. Wired remote controller (UTY-RVNYM: Optional part)
¢
Overview
a
b
c
d
e
f
g
h
i
a Display panel (with backlight)
b Screen switch button (Left)
c Menu button
d Cancel button
e Cursor button
f Screen switch button (Right)
g Power indicator
h On/off button
i Enter button
- 275 -
