6-2. Cooling capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AOYG36KBTA5
Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
54
-10.0 8.6 2.31 9.7 2.36 10.3 2.37 11.0 2.40 11.8 2.43 12.1 2.44
0.0 8.6 2.08 9.7 2.12 10.3 2.13 11.0 2.16 11.8 2.18 12.1 2.19
5.0 8.6 1.94 9.7 1.97 10.3 1.99 11.0 2.01 11.8 2.04 12.1 2.05
10.0 8.6 1.88 9.7 1.91 10.3 1.93 11.0 1.95 11.8 1.97 12.1 1.98
15.0 8.6 1.98 9.7 2.01 10.3 2.03 11.0 2.05 11.8 2.08 12.1 2.09
20.0 8.6 1.97 9.7 2.00 10.3 2.02 11.0 2.04 11.8 2.07 12.1 2.08
25.0 8.6 2.23 9.7 2.27 10.3 2.29 11.0 2.31 11.8 2.34 12.1 2.35
30.0 8.6 2.68 9.7 2.72 10.3 2.75 11.0 2.78 11.8 2.81 12.1 2.82
35.0 8.6 3.23 9.7 3.29 10.3 3.31 11.0 3.35 11.8 3.39 12.1 3.41
40.0 6.4 2.40 7.2 2.45 7.6 2.47 8.2 2.49 8.7 2.52 9.0 2.54
46.0 4.2 1.58 4.7 1.61 5.0 1.62 5.3 1.64 5.7 1.66 5.9 1.67
53
-10.0 8.6 2.31 9.7 2.36 10.3 2.37 11.0 2.40 11.8 2.43 12.1 2.44
0.0 8.6 2.08 9.7 2.12 10.3 2.13 11.0 2.16 11.8 2.18 12.1 2.19
5.0 8.6 1.94 9.7 1.97 10.3 1.99 11.0 2.01 11.8 2.04 12.1 2.05
10.0 8.6 1.88 9.7 1.91 10.3 1.93 11.0 1.95 11.8 1.97 12.1 1.98
15.0 8.6 1.98 9.7 2.01 10.3 2.03 11.0 2.05 11.8 2.08 12.1 2.09
20.0 8.6 1.97 9.7 2.00 10.3 2.02 11.0 2.04 11.8 2.07 12.1 2.08
25.0 8.6 2.23 9.7 2.27 10.3 2.29 11.0 2.31 11.8 2.34 12.1 2.35
30.0 8.6 2.68 9.7 2.72 10.3 2.75 11.0 2.78 11.8 2.81 12.1 2.82
35.0 8.6 3.23 9.7 3.29 10.3 3.31 11.0 3.35 11.8 3.39 12.1 3.41
40.0 6.4 2.40 7.2 2.45 7.6 2.47 8.2 2.49 8.7 2.52 9.0 2.54
46.0 4.2 1.58 4.7 1.61 5.0 1.62 5.3 1.64 5.7 1.66 5.9 1.67
52
-10.0 8.6 2.31 9.7 2.36 10.3 2.37 11.0 2.40 11.8 2.43 12.1 2.44
0.0 8.6 2.08 9.7 2.12 10.3 2.13 11.0 2.16 11.8 2.18 12.1 2.19
5.0 8.6 1.94 9.7 1.97 10.3 1.99 11.0 2.01 11.8 2.04 12.1 2.05
10.0 8.6 1.88 9.7 1.91 10.3 1.93 11.0 1.95 11.8 1.97 12.1 1.98
15.0 8.6 1.98 9.7 2.01 10.3 2.03 11.0 2.05 11.8 2.08 12.1 2.09
20.0 8.6 1.97 9.7 2.00 10.3 2.02 11.0 2.04 11.8 2.07 12.1 2.08
25.0 8.6 2.23 9.7 2.27 10.3 2.29 11.0 2.31 11.8 2.34 12.1 2.35
30.0 8.6 2.68 9.7 2.72 10.3 2.75 11.0 2.78 11.8 2.81 12.1 2.82
35.0 8.6 3.23 9.7 3.29 10.3 3.31 11.0 3.35 11.8 3.39 12.1 3.41
40.0 6.4 2.40 7.2 2.45 7.6 2.47 8.2 2.49 8.7 2.52 9.0 2.54
46.0 4.2 1.58 4.7 1.61 5.0 1.62 5.3 1.64 5.7 1.66 5.9 1.67
51
-10.0 8.6 2.31 9.7 2.36 10.3 2.37 11.0 2.40 11.8 2.43 12.1 2.44
0.0 8.6 2.08 9.7 2.12 10.3 2.13 11.0 2.16 11.8 2.18 12.1 2.19
5.0 8.6 1.94 9.7 1.97 10.3 1.99 11.0 2.01 11.8 2.04 12.1 2.05
10.0 8.6 1.88 9.7 1.91 10.3 1.93 11.0 1.95 11.8 1.97 12.1 1.98
15.0 8.6 1.98 9.7 2.01 10.3 2.03 11.0 2.05 11.8 2.08 12.1 2.09
20.0 8.6 1.97 9.7 2.00 10.3 2.02 11.0 2.04 11.8 2.07 12.1 2.08
25.0 8.6 2.23 9.7 2.27 10.3 2.29 11.0 2.31 11.8 2.34 12.1 2.35
30.0 8.6 2.68 9.7 2.72 10.3 2.75 11.0 2.78 11.8 2.81 12.1 2.82
35.0 8.6 3.23 9.7 3.29 10.3 3.31 11.0 3.35 11.8 3.39 12.1 3.41
40.0 6.4 2.40 7.2 2.45 7.6 2.47 8.2 2.49 8.7 2.52 9.0 2.54
46.0 4.2 1.58 4.7 1.61 5.0 1.62 5.3 1.64 5.7 1.66 5.9 1.67
50
-10.0 8.6 2.31 9.7 2.36 10.3 2.37 11.0 2.40 11.8 2.43 12.1 2.44
0.0 8.6 2.08 9.7 2.12 10.3 2.13 11.0 2.16 11.8 2.18 12.1 2.19
5.0 8.6 1.94 9.7 1.97 10.3 1.99 11.0 2.01 11.8 2.04 12.1 2.05
10.0 8.6 1.88 9.7 1.91 10.3 1.93 11.0 1.95 11.8 1.97 12.1 1.98
15.0 8.6 1.98 9.7 2.01 10.3 2.03 11.0 2.05 11.8 2.08 12.1 2.09
20.0 8.6 1.97 9.7 2.00 10.3 2.02 11.0 2.04 11.8 2.07 12.1 2.08
25.0 8.6 2.23 9.7 2.27 10.3 2.29 11.0 2.31 11.8 2.34 12.1 2.35
30.0 8.6 2.68 9.7 2.72 10.3 2.75 11.0 2.78 11.8 2.81 12.1 2.82
35.0 8.6 3.23 9.7 3.29 10.3 3.31 11.0 3.35 11.8 3.39 12.1 3.41
40.0 6.4 2.40 7.2 2.45 7.6 2.47 8.2 2.49 8.7 2.52 9.0 2.54
46.0 4.2 1.58 4.7 1.61 5.0 1.62 5.3 1.64 5.7 1.66 5.9 1.67
49
-10.0 8.6 2.31 9.7 2.36 10.3 2.37 11.0 2.40 11.8 2.43 12.1 2.44
0.0 8.6 2.08 9.7 2.12 10.3 2.13 11.0 2.16 11.8 2.18 12.1 2.19
5.0 8.6 1.94 9.7 1.97 10.3 1.99 11.0 2.01 11.8 2.04 12.1 2.05
10.0 8.6 1.88 9.7 1.91 10.3 1.93 11.0 1.95 11.8 1.97 12.1 1.98
15.0 8.6 1.98 9.7 2.01 10.3 2.03 11.0 2.05 11.8 2.08 12.1 2.09
20.0 8.6 1.97 9.7 2.00 10.3 2.02 11.0 2.04 11.8 2.07 12.1 2.08
25.0 8.6 2.23 9.7 2.27 10.3 2.29 11.0 2.31 11.8 2.34 12.1 2.35
30.0 8.6 2.68 9.7 2.72 10.3 2.75 11.0 2.78 11.8 2.81 12.1 2.82
35.0 8.6 3.23 9.7 3.29 10.3 3.31 11.0 3.35 11.8 3.39 12.1 3.41
40.0 6.4 2.40 7.2 2.45 7.6 2.47 8.2 2.49 8.7 2.52 9.0 2.54
46.0 4.2 1.58 4.7 1.61 5.0 1.62 5.3 1.64 5.7 1.66 5.9 1.67
48
-10.0 8.6 2.31 9.7 2.36 10.3 2.37 11.0 2.40 11.8 2.43 12.1 2.44
0.0 8.6 2.08 9.7 2.12 10.3 2.13 11.0 2.16 11.8 2.18 12.1 2.19
5.0 8.6 1.94 9.7 1.97 10.3 1.99 11.0 2.01 11.8 2.04 12.1 2.05
10.0 8.6 1.88 9.7 1.91 10.3 1.93 11.0 1.95 11.8 1.97 12.1 1.98
15.0 8.6 1.98 9.7 2.01 10.3 2.03 11.0 2.05 11.8 2.08 12.1 2.09
20.0 8.6 1.97 9.7 2.00 10.3 2.02 11.0 2.04 11.8 2.07 12.1 2.08
25.0 8.6 2.23 9.7 2.27 10.3 2.29 11.0 2.31 11.8 2.34 12.1 2.35
30.0 8.6 2.68 9.7 2.72 10.3 2.75 11.0 2.78 11.8 2.81 12.1 2.82
35.0 8.6 3.23 9.7 3.29 10.3 3.31 11.0 3.35 11.8 3.39 12.1 3.41
40.0 6.4 2.40 7.2 2.45 7.6 2.47 8.2 2.49 8.7 2.52 9.0 2.54
46.0 4.2 1.58 4.7 1.61 5.0 1.62 5.3 1.64 5.7 1.66 5.9 1.67
- 484 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
