4. INDOOR UNITS
nit  
INSTALLATION PLACE
Left Right
300 or more 300 or more
Ceiling
Left
Indoor unit
Right
150 or more 300 or more
Ceiling
20 or more
1000 or more
2300 or more
Obstruction
Floor
    
INDOOR
UNITS
INDOOR
UNITS
