2. MODEL SELECTION
CAPACITY TABLE (INDOOR UNIT)6.
COOLING CAPACITY6-1.
COMPACT CASSETTE TYPE6-1-1.
MODEL : AU
 
G07LVLA
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 1.64 1.24 1.80 1.38 1.93 1.49 2.05 1.60 2.27 1.76 2.47 1.84 2.67 1.89
0.0 1.64 1.24 1.80 1.38 1.93 1.49 2.05 1.60 2.27 1.76 2.47 1.84 2.67 1.89
5.0 1.64 1.24 1.80 1.38 1.93 1.49 2.05 1.60 2.27 1.76 2.47 1.84 2.67 1.89
10.0 1.64 1.24 1.80 1.38 1.93 1.49 2.05 1.60 2.27 1.76 2.47 1.84 2.67 1.89
15.0 1.64 1.24 1.80 1.38 1.93 1.49 2.05 1.60 2.27 1.76 2.47 1.84 2.67 1.89
20.0 1.64 1.24 1.80 1.38 1.93 1.49 2.05 1.60 2.27 1.76 2.47 1.84 2.51 1.86
25.0 1.64 1.24 1.80 1.38 1.93 1.49 2.05 1.60 2.27 1.76 2.38 1.78 2.45 1.80
30.0 1.64 1.24 1.80 1.38 1.93 1.49 2.05 1.60 2.27 1.76 2.30 1.73 2.36 1.76
35.0 1.64 1.24 1.80 1.38 1.93 1.49 2.05 1.60 2.16 1.69 2.24 1.69 2.28 1.74
40.0 1.64 1.24 1.80 1.38 1.88 1.48 1.93 1.59 2.04 1.62 2.11 1.61 2.15 1.66
46.0 1.64 1.24 1.60 1.27 1.77 1.42 1.82 1.51 1.91 1.53 1.99 1.52 2.03 1.58
MODEL : AU
 
G09LVLA
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 2.11 1.57 2.32 1.75 2.49 1.90 2.64 2.03 2.92 2.23 3.18 2.33 3.43 2.40
0.0 2 .11 1.57 2.32 1.75 2.49 1.90 2.64 2.03 2.92 2.23 3.18 2.33 3.43 2.40
5.0 2 .11 1.57 2.32 1.75 2.49 1.90 2.64 2.03 2.92 2.23 3.18 2.33 3.43 2.40
10.0 2.11 1.57 2.32 1.75 2.49 1.90 2.64 2.03 2.92 2.23 3.18 2.33 3.43 2.40
15.0 2.11 1.57 2.32 1.75 2.49 1.90 2.64 2.03 2.92 2.23 3.18 2.33 3.43 2.40
20.0 2.11 1.57 2.32 1.75 2.49 1.90 2.64 2.03 2.92 2.23 3 .18 2.33 3.23 2.36
25.0 2.11 1.57 2.32 1.75 2.49 1.90 2.64 2.03 2.92 2.23 3.07 2.26 3.15 2.28
30.0 2.11 1.57 2.32 1.75 2.49 1.90 2.64 2.03 2.92 2.23 2.96 2.19 3.04 2.24
35.0 2.11 1.57 2.32 1.75 2.49 1.90 2.64 2.03 2.78 2.15 2.89 2.15 2.94 2.21
40.0 2.11 1.57 2.32 1.75 2.42 1.88 2.49 2.02 2.62 2.06 2.72 2.04 2.77 2 .11
46.0 2 .11 1.57 2.06 1.62 2.28 1.80 2.34 1.92 2.47 1.95 2.56 1.93 2.61 2.01
MODEL : AU
 
G12LVLA, AU

G12LVLB
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 2.82 1.94 3.10 2.28 3.32 2.47 3.52 2.66 3.89 2.88 4.23 3.05 4.58 3 .16
0.0 2.82 1.94 3.10 2.28 3.32 2.47 3.52 2.66 3.89 2.88 4.23 3.05 4.58 3.16
5.0 2.82 1.94 3.10 2.28 3.32 2.47 3.52 2.66 3.89 2.88 4.23 3.05 4.58 3.16
10.0 2.82 1.94 3.10 2.28 3.32 2.47 3.52 2.66 3.89 2.88 4.23 3.05 4.58 3.16
15.0 2.82 1.94 3.10 2.28 3.32 2.47 3.52 2.66 3.89 2.88 4.23 3.05 4.58 3.16
20.0 2.82 1.94 3.10 2.28 3.32 2.47 3.52 2.66 3.89 2.88 4.23 3.05 4.30 3.10
25.0 2.82 1.94 3.10 2.28 3.32 2.47 3.52 2.66 3.89 2.88 4.09 2.95 4.20 3.00
30.0 2.82 1.94 3.10 2.28 3.32 2.47 3.52 2.66 3.89 2.88 3.95 2.87 4.06 2.94
35.0 2.82 1.94 3.10 2.28 3.32 2.47 3.52 2.66 3.71 2.78 3.85 2.81 3.92 2.90
40.0 2.82 1.94 3.10 2.28 3.23 2.45 3.32 2.61 3.50 2.66 3.63 2.67 3.70 2.77
46.0 2.82 1.94 2.75 2.08 3.03 2.35 3.12 2.51 3.29 2.52 3.41 2.53 3.48 2.64
MODEL : AU
 
G14LVLA, AU

G14LVLB
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
0.0 3.28 2.15 3.61 2.53 3.86 2.74 4 .10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
5.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
10.0 3.28 2 .15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
15.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
20.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.01 3.43
25.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.77 3.27 4.89 3.33
30.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.60 3 .18 4.73 3.26
35.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.32 3.09 4.48 3.11 4.57 3.22
40.0 3.28 2.15 3.61 2.53 3.76 2.73 3.87 2.90 4.07 2.95 4.23 2.96 4.31 3.08
46.0 3.28 2.15 3.20 2.31 3.53 2.62 3.64 2.80 3.83 2.80 3.97 2.80 4.05 2.94
COOLING CAPACITY
TC : Total Capacity kW.
SHC : Sensible Heat Capacity kW.
The data is based on the following conditions.
Pipe length : 5m [Outdoor unit - Branch box], 3m [Branch box - Indoor unit]
Height difference : 0m [Outdoor unit - Indoor unit].
- (02 - 18) -
