4. INDOOR UNITS
SLIM DUCT TYPE
CenterCenter
Front viewSide view
1.5m
2m 1m
Microphone
Measuring duct Measuring duct
Microphone
WALL MOUNTED TYPE
1m
0.8m
Microphone Microphone
    
INDOOR
UNITS
INDOOR
UNITS
