5. CONTROL SYSTEM
PACKING LIST
Name and shape Quantity Application
Installation manual 1
Operating manual 1
Remote controller cable
(10m)
1
For connecting the remote controller
Screw
(M4 x 16mm)
2
For installing the remote controller
Cable tie 1
To tie the remote controller and cables
Connecting cable *1 1
For connecting the remote controller cable to the Wall
mounted type indoor unit
Screw *1
(M4 x 14mm)
1
For installing the remote controller cable to the
indoor unit
Cable clamper *1 1
For installing the remote controller cable to the indoor
unit
*1:
se on i the reote controer cabe ust be odied or the indoor unit ode.
WIRING SPECIFICATIONS
Use Cable size Wire type Remarks
Remote controller
cable
0.33 mm
2
(22AWG)
Polar 3 core Use sheathed PVC cable
SPECIFICATIONS
Dimensions [H x W x D]: (mm) 120 x 75 x 14
Weight: (g) 90
PART (OPTIONAL)
Wall mounted type
Model name
AS
G07LJCA
AS
G09LJCA
AS
G12LJCA
AS
G07LUCA
AS
G09LUCA
AS
G12LUCA
AS
G14LUCA
AS
G07LMCA
AS
G09LMCA
AS
G12LMCA
AS
G14LMCA
UT Y-XCBX Z1 UTY-TWBXF UTY-XCBX Z2
*The communication kit is necessary for connecting the wired remote controller to the Wall mounted type.
