6. SYSTEM DESIGN
WIRING RULES

Example 1 (prohibited)

Branch box
Power cable
Power cable
Do not connect the power cable directly to indoor units.
Always supply power to indoor units from a branch box.
- (06 - 43) -
SYSTEM
DESIGN
SYSTEM
DESIGN
