2. MODEL SELECTION
MODEL : AR
 
G18LLTA, AR
îš¾
G18LLTB
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 4.24 2.93 4.69 3.33 5.00 3.57 5.27 3.69 5.85 4.07 6.38 4.46 6.85 4.52
0.0 4.24 2.93 4.69 3.33 5.00 3.57 5.27 3.69 5.85 4.07 6.38 4.46 6.85 4.52
5.0 4.24 2.93 4.69 3.33 5.00 3.57 5.27 3.69 5.85 4.07 6.38 4.46 6.85 4.52
10.0 4.24 2.93 4.69 3.33 5.00 3.57 5.27 3.69 5.85 4.07 6.38 4.46 6.85 4.52
15.0 4.24 2.93 4.69 3.33 5.00 3.57 5.27 3.69 5.85 4.07 6.38 4.46 6.85 4.52
20.0 4.24 2.93 4.69 3.33 5.00 3.57 5.27 3.69 5.85 4.07 6.38 4.46 6.48 4.47
25.0 4.24 2.93 4.69 3.33 5.00 3.57 5.27 3.69 5.85 4.07 6.17 4.31 6.32 4.33
30.0 4.24 2.93 4.69 3.33 5.00 3.57 5.27 3.69 5.85 4.07 5.96 4.19 6.11 4.25
35.0 4.24 2.93 4.69 3.33 5.00 3.57 5.27 3.69 5.56 3.92 5.80 4.11 5.90 4.19
40.0 4.24 2.93 4.69 3.33 4.86 3.55 4.97 3.68 5.24 3.75 5.47 3.90 5.57 4.01
46.0 4.24 2.93 4.16 3.08 4.57 3.41 4.67 3.51 4.93 3.55 5.14 3.70 5.24 3.82
COOLING CAPACITY
TC : Total Capacity kW.
SHC : Sensible Heat Capacity kW.
The data is based on the following conditions.
Pipe length : 5m [Outdoor unit - Branch box], 3m [Branch box - Indoor unit]
Height difference : 0m [Outdoor unit - Indoor unit].
- (02 - 21) -
