2. MODEL SELECTION
FLOOR / CEILING TYPE6-1-4.
MODEL : AB
 
G14LVTA
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
0.0 3.28 2.15 3.61 2.53 3.86 2.74 4 .10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
5.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
10.0 3.28 2 .15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
15.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
20.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.01 3.43
25.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.77 3.27 4.89 3.33
30.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.60 3 .18 4.73 3.26
35.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.32 3.09 4.48 3.11 4.57 3.22
40.0 3.28 2.15 3.61 2.53 3.76 2.73 3.87 2.90 4.07 2.95 4.23 2.96 4.31 3.08
46.0 3.28 2.15 3.20 2.31 3.53 2.62 3.64 2.80 3.83 2.80 3.97 2.80 4.05 2.94
MODEL : AB
 
G18LVTA, AB

G18LV TB
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 4.22 2.68 4.64 3.16 4.96 3.43 5.27 3.69 5.82 3.99 6.34 4.22 6.85 4.35
0.0 4.22 2.68 4.64 3 .16 4.96 3.43 5.27 3.69 5.82 3.99 6.34 4.22 6.85 4.35
5.0 4.22 2.68 4.64 3.16 4.96 3.43 5.27 3.69 5.82 3.99 6.34 4.22 6.85 4.35
10.0 4.22 2.68 4.64 3.16 4.96 3.43 5.27 3.69 5.82 3.99 6.34 4.22 6.85 4.35
15.0 4.22 2.68 4.64 3 .16 4.96 3.43 5.27 3.69 5.82 3.99 6.34 4.22 6.85 4.35
20.0 4.22 2.68 4.64 3 .16 4.96 3.43 5.27 3.69 5.82 3.99 6.34 4.22 6.45 4.29
25.0 4.22 2.68 4.64 3 .16 4.96 3.43 5.27 3.69 5.82 3.99 6.13 4.08 6.29 4.15
30.0 4.22 2.68 4.64 3 .16 4.96 3.43 5.27 3.69 5.82 3.99 5.92 3.97 6.08 4.07
35.0 4.22 2.68 4.64 3 .16 4.96 3.43 5.27 3.69 5.55 3.86 5.76 3.89 5.87 4.02
40.0 4.22 2.68 4.64 3 .16 4.83 3.41 4.97 3.63 5.23 3.69 5.43 3.69 5.54 3.85
46.0 4.22 2.68 4.11 2.89 4.54 3.27 4.67 3.51 4.92 3.49 5.11 3.50 5.21 3.67
COOLING CAPACITY
TC : Total Capacity kW.
SHC : Sensible Heat Capacity kW.
The data is based on the following conditions.
Pipe length : 5m [Outdoor unit - Branch box], 3m [Branch box - Indoor unit]
Height difference : 0m [Outdoor unit - Indoor unit].
- (02 - 26) -
