3. OUTDOOR UNIT & BRANCH BOX
BRANCH BOX1-2.
Model name UTP-PY03A UTP-PY02A
Casing color Paintingless Paintingless
Connectable indoor unit 1 to 3 Units 1 to 2 Units
Power source 1ø 230V ~ 50Hz 1ø 230V ~ 50Hz
Available voltage range 198-264V 198-264V
Input Power W 10 10
Running current A 0.05 0.05
Refrigerant type R410A R410A
Dimensions
(H × W × D)
Net
mm
195×433×370 195×433×370
Gross 271×931×436 271×931×436
Weight
Net
kg
9 9
Gross 13 13
Connection
pipe
Size
Liquid
mm
Main : 9.52 ×1, Branch : 6.35 ×3 Main : 9.52 ×1, Branch : 6.35 ×2
Gas Main : 15.88 ×1, Branch : 12.7 ×3 Main : 15.88 ×1, Branch : 12.7 ×2
Method Flare Flare
Operation range
°C -15 to 46 -15 to 46
%RH 80 or less 80 or less
Note :
pecications are based on the oowing conditions.
Power source o specications .
- (03 - 02) -
OUTDOOR
UNITS
OUTDOOR
UNITS
To Next Page
