En-5
5. AIRFLOW SETTINGS
5.1. Fan speed setting
)
Press to control the fan speed.
The fan speed changes as follows.
(Auto) (High) (Med) (Low) (Quiet)
When
is selected, the fan speed depends on the operating
condition.
To increase the air cleaning e󰀨ect, set the fan speed to High.
5.2. Airow direction setting
For details of the airow ranges, refer to "Airow direction range".
■
Up/down airow direction setting
)
Press to adjust the up/down airow direction.
■
Left/right airow direction setting
CAUTION
Before you adjust the left/right airow direction, make
sure that the horizontal louver has been stopped
completely.
)
Adjust two knobs of the vertical louvers by hand.
4. BASIC OPERATIONS
■
3 steps to start operation
1. Press
to start or stop the operation.
2. Press
to select the operation mode.
The operation mode changes as follows.
(Auto) (Cooling) (Dry) (Fan) (Heating)
3. Press
to set the desired temperature.
The temperature changes by 0.5 °C increments.
Temperature setting range
Auto/Cooling/Dry 18.0 - 30.0 °C
Heating 16.0 - 30.0 °C
NOTES:
• In the Cooling mode, the indoor unit fan may stop from time to time
to perform Fan control for energy saving that enables power-saving
operation by stopping the rotation of the indoor unit fan when the
outdoor unit is stopped.
In initial setting, this function is activated.
To deactivate the function, refer to “7.3. Fan control for energy saving”.
• In the Cooling or Dry mode, set the temperature lower than the
current room temperature.
• In the Heating mode,
- set the temperature higher than the current room temperature.
- at the beginning of the operation, the indoor unit fan rotates at very
low speed for 3-5 minutes.
- the Automatic defrosting operation overrides the Heating operation
when necessary.
• In the Fan mode, temperature control is not available.
■
Temperature unit switching
1. Press
until only the clock is displayed.
2. Press and hold
for more than 5 seconds.
The current temperature unit will be displayed. (Factory setting: °C)
3. Press
to switch the temperature unit. (°C
⇔
°F)
4. Press
to nish the setting.
If you do not press the button for 30 seconds, the displayed
temperature unit will be set.
3.3. Inserting batteries
Battery type: R03/LR03/AAA x 2
6
8
7
5
9
1
RESET
4
2 3
1 Pull the cover in the direction of the arrow and open it
until it is trapped.
2 Remove the cover.
1
Turn the remote controller over and push the back
side of the cover and remove the claws by curving
the cover.
2
Pull in the direction of the arrow while curving the
cover.
3 Put batteries as shown in the gure above.
4 Press this button as shown in the gure above.
Use the tip of a ballpoint pen or other small objects.
5 Press
to start clock setting.
6 Press
()
to set day of the week (Monday to
Sunday).
* By pressing , the time indicator can be changed
from a 12-hour to a 24-hour clock.
7
Press
to continue.
8 Press
()
to set the clock.
Press the buttons to change the clock by a minute.
Press and hold the buttons to change the clock by 10 minutes.
9
Press
to complete the setting.
Be close to the indoor unit. If you press the button from a
distance, settings may not be properly sent.
10
Install and close the cover.
NOTES:
• Use specied type of batteries only.
• Do not mix di󰀨erent types or new and used batteries together.
• Batteries can be used about 1 year in ordinary use.
• If the remote control range noticeably shortens, replace the
batteries, and press
as shown in the gure above.
9387602296-01_OM.indb 59387602296-01_OM.indb 5 17-Feb-22 14:56:0117-Feb-22 14:56:01
