Fujitsu ASYG09LLCE Service Instruction

03-02
( Factory setting)
Setting Description
Function Number Setting Value
Yes
No
40
00
01
1-4. Setting the Auto Restart
Enable or disable automatic system restart after a power outage.
*Auto restart is an emergency function such as for power failure etc. Do not start and stop the indoor
unit by this function in normal operation.
Be sure to operate by the control unit, or external input device.
( Factory setting)
Setting Description
Function Number Setting Value
A
B
C
D
44
00
01
02
03
1-5. Remote controller signal code
Change the indoor unit Signal Code, depending on the remote controllers.
* If setting value is "00" :
When the outdoor unit is stopped, the indoor unit fan operates following the setting on the
remote controller continuously.
* If setting value is "01" :
When the outdoor unit is stopped, the indoor unit fan operates at very low speed intermittently.
( Factory setting)
Setting Description
Function Number Setting Value
No
Yes
49
00
01
1-6. Indoor unit fan control for energy saving (Only cooling mode)
Enable or disable indoor unit fan control when the outdoor unit is stopped.

Fujitsu ASYG09LLCE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Product color	White
Inverter technology	Yes
Refrigerating medium	R410A
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	650 g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 43 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Heating capacity in watts (nominal) (Average heating season)	3000 W
Airflow	1670 m³/h
Outdoor unit noise level	- dB
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Annual energy consumption (cooling)	127 kWh
Hourly energy consumption (cooling)	- kWh
Indoor unit type	Wall-mountable
Indoor unit depth	206 mm
Indoor unit width	820 mm
Indoor unit height	262 mm
Indoor unit weight	7000 g
Indoor unit noise level (high speed)	720 dB
