WALL MOUNTED TYPE AS

G09-14LT
WALL MOUNTED TYPE AS

G09-14LT
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL

:AS

G09LT
MODEL

:AS

G12LT
MODEL

:AS

G14LT
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
AFR 13.3
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 2.34 1.62 0.35 2.61 1.63 0.36 2.70 1.77 0.36 2.87 1.78 0.37 2.96 1.92 0.37 3.14 1.91 0.37 3.32 2.04 0.37
25 2.22 1.54 0.40 2.48 1.55 0.40 2.56 1.68 0.41 2.73 1.69 0.41 2.81 1.82 0.41 2.98 1.82 0.42 3.15 1.93 0.42
30 2.10 1.45 0.44 2.34 1.46 0.45 2.42 1.59 0.45 2.58 1.60 0.46 2.66 1.72 0.46 2.82 1.72 0.46 2.98 1.83 0.47
35 1.98 1.37 0.49 2.20 1.38 0.49 2.28 1.50 0.50 2.43 1.50 0.50 2.50 1.62 0.51 2.65 1.61 0.51 2.80 1.72 0.52
40 1.76 1.22 0.49 1.96 1.23 0.49 2.03 1.33 0.50 2.16 1.34 0.50 2.23 1.44 0.50 2.36 1.44 0.51 2.50 1.53 0.51
43 1.63 1.13 0.49 1.82 1.14 0.49 1.88 1.24 0.50 2.00 1.24 0.50 2.07 1.34 0.50 2.19 1.33 0.51 2.31 1.42 0.51
AFR 14.2
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 3.28 2.28 0.58 3.65 2.30 0.59 3.77 2.50 0.59 4.02 2.50 0.60 4.15 2.70 0.60 4.40 2.69 0.61 4.64 2.87 0.62
25 3.12 2.17 0.66 3.47 2.18 0.67 3.59 2.37 0.67 3.83 2.38 0.68 3.95 2.57 0.68 4.18 2.56 0.69 4.42 2.72 0.70
30 2.95 2.05 0.74 3.28 2.06 0.75 3.40 2.24 0.75 3.62 2.25 0.76 3.73 2.43 0.77 3.96 2.42 0.77 4.18 2.57 0.78
35 2.77 1.93 0.82 3.08 1.94 0.83 3.19 2.11 0.84 3.40 2.11 0.85 3.50 2.28 0.85 3.71 2.27 0.86 3.92 2.42 0.87
40 2.34 1.72 0.76 2.60 1.73 0.77 2.69 1.88 0.78 2.87 1.88 0.79 2.96 2.03 0.79 3.14 2.02 0.80 3.31 2.16 0.81
43 2.15 1.59 0.76 2.40 1.60 0.78 2.48 1.74 0.78 2.64 1.75 0.79 2.72 1.89 0.79 2.89 1.88 0.80 3.05 2.00 0.81
AFR 15.0
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 3.91 2.76 0.81 4.35 2.78 0.82 4.50 3.02 0.82 4.80 3.03 0.83 4.95 3.27 0.84 5.24 3.26 0.85 5.54 3.47 0.85
25 3.72 2.63 0.91 4.15 2.65 0.93 4.29 2.88 0.93 4.57 2.89 0.94 4.71 3.12 0.94 5.00 3.11 0.95 5.28 3.31 0.96
30 3.53 2.50 1.01 3.93 2.51 1.03 4.07 2.73 1.03 4.34 2.74 1.04 4.47 2.96 1.05 4.74 2.95 1.06 5.01 3.14 1.07
35 3.32 2.35 1.12 3.70 2.36 1.14 3.82 2.56 1.14 4.07 2.57 1.15 4.20 2.78 1.16 4.45 2.77 1.17 4.70 2.95 1.18
40 2.92 2.06 1.10 3.25 2.07 1.12 3.36 2.25 1.13 3.58 2.26 1.14 3.69 2.44 1.14 3.91 2.43 1.15 4.13 2.59 1.17
43 2.66 1.88 1.09 2.96 1.89 1.10 3.06 2.05 1.11 3.26 2.06 1.12 3.36 2.22 1.13 3.56 2.22 1.14 3.77 2.36 1.15
