6. SYSTEM DESIGN
Pipe size table "A"

etween outdoor unit and rst separation tube
Outside diameter mm (in)
Liquid pipe Gas pipe
9.52 (3/8") 15.88 (5/8")
Pipe size table "B"

etween rst separation tube and second separation tube
Outside diameter mm (in)
Liquid pipe Gas pipe
9.52 (3/8") 15.88 (5/8")
Pipe size table "C"

(Between separation tube and branch box)
Outside diameter mm (in)
Liquid pipe Gas pipe
9.52 (3/8") 15.88 (5/8")
Pipe size table "D"

(Between branch box and indoor unit)
Model code of
indoor unit
Outside diameter mm (in)
Liquid pipe Gas pipe
07, 09, 12 6.35 (1/4") 9.52 (3/8")
14, 18 6.35 (1/4") 12.70 (1/2")
24 6.35 (1/4") 15.88 (5/8")
- (06 - 16) -
SYSTEM DESIGN SYSTEM DESIGN
