6. SYSTEM DESIGN
CONTROLLER CABLE WIRING4-4.
WIRING SPECIFICATIONS

Model type Connection to Wire Cable size pecication
Central remote
controller
Branch box
Remote controller
cable
0.33 mm
2
Sheathed PVC cable Polar
3core
Wired Remote
Controller
Indoor unit
Remote controller
cable
0.33 mm
2
Simple Remote
Controller
Indoor unit
IR Receiver Unit Indoor unit Connection cable - (5m cable attached)
Caution
Install in accordance with local rules and regulations.îž”
Never bundle the power supply cable and controller cable together. Bundling these cords together îž”
will cause misoperation.
Always ground the shilded cable at both ends.îž”
For detail specification and connection, please refer to "5 Control system".îž”
- (06 - 48) -
