Fujitsu ASYG09LZCA User Manual

- 8 -
WALL MOUNTED ASYG09-14LZCA
3. Specifications
Type
Wall mounted
Inverter heat pump
Model name
ASYG09LZCA
ASYG12LZCA ASYG14LZCA
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 2.50 3.50 4.20
Btu/h 8,500 11,900 14,300
Min.—Max.
kW 0.90—4.65 0.90—4.80 0.90—6.40
Btu/h 3,100—15,800 3,100—16,300 3,100—21,800
Heating
Rated
kW 3.20 4.00 5.40
Btu/h 10,900 13,600 18,400
Min.—Max.
kW 0.90—7.20 0.90—7.40 0.90—8.90
Btu/h 3,100—24,500 3,100—25,200 3,100—30,300
Input power
Cooling
Rated
kW
0.48 0.80 1.05
Max. 0.85 0.99 1.56
Heating
Rated 0.555 0.76 1.17
Max. 1.93 1.94 2.19
Fan
HIGH
W
23 23 32
MED 13 13 20
LOW 9 9 12
QUIET 5 5 6
Current
Cooling
Rated A
2.7 4.0 4.8
Heating 2.9 3.9 5.3
EER Cooling
kW/kW
5.21 4.38 4.00
COP Heating 5.77 5.26 4.62
Power factor
Cooling
%
77 87 95
Heating 83 85 96
Moisture removal L/h (pints/h) 1.0 (2.1) 1.1 (2.3) 1.7 (3.6)
Maximum operating current *1
Cooling
A
9.4 9.4 9.9
Heating 11.9 11.9 14.9
Fan
Airflow rate
Cooling
HIGH
m
3
/h
830 900
MED 680 780
LOW 580 630
QUIET 380 440
Heating
HIGH 830 900
MED 680 780
LOW 580 630
QUIET 380 500
Type × Q'ty Cross flow fan × 1
Motor output W 61
Sound pressure level *2
Cooling
HIGH
dB (A)
42 45
MED 37 40
LOW 32 34
QUIET 23 26
Heating
HIGH 41 44
MED 35 39
LOW 31 33
QUIET 23 27
Heat exchanger type
Dimensions (H × W × D)
mm
Main: 384 × 720 × 30
Sub 1: 84 × 720 × 13.3
Sub 2: 126 × 720 × 13.3
Fin pitch Main: 1.2, Sub 1 and Sub 2: 1.4
Rows × Stages Main: 3 × 24, Sub 1: 1 × 4, Sub 2: 1 × 6
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of MUNSELL 5PB 9.25/0.5
Dimensions
(H × W × D)
Net
mm
295 × 940 × 270
Gross 365 × 1,040 × 355
Weight
Net
kg
14
Gross 17
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8) Ø 12.7 (Ø 1/2)
Method Flare
Drain hose
Material PP+LLDPF
Size mm Ø 13.8 (I.D.), Ø 15.8 to Ø 16.7 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Wired [option])
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/ 19 °CWB, and outdoor temperature of 35 °CDB/ 24 °CWB.
– Heating: Indoor temperature of 20 °CDB/ 15 °CWB, and outdoor temperature of 7 °CDB/ 6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum current is maximum value when operated within the operation range.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
