WALL MOUNTED ASYG09-14LZCA
6-2. Heating capacity
 Model: ASYG09LZCA
 Model: ASYG12LZCA
 Model: ASYG14LZCA
AFR
m
3
/h
830
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 3.53 2.15 3.44 2.19 3.36 2.23 3.27 2.32 3.19 2.36
-20 -21 4.45 2.16 4.34 2.20 4.24 2.24 4.13 2.33 4.02 2.38
-15 -16 4.88 2.17 4.77 2.21 4.65 2.25 4.53 2.34 4.42 2.39
-10 -11 5.19 2.13 5.07 2.17 4.95 2.22 4.82 2.30 4.70 2.35
-5 -7 5.50 2.10 5.37 2.14 5.24 2.18 5.11 2.27 4.98 2.31
0 -2 5.65 2.06 5.52 2.10 5.38 2.14 5.25 2.23 5.11 2.27
5 3 6.97 1.88 6.81 1.92 6.64 1.95 6.47 2.03 6.31 2.07
7 6 7.55 1.85 7.38 1.89 7.20 1.93 7.02 2.01 6.84 2.05
10 8 8.35 1.84 8.15 1.88 7.95 1.91 7.75 1.99 7.55 2.03
15 10 8.65 1.63 8.45 1.67 8.24 1.70 8.03 1.77 7.83 1.80
20 15 8.97 1.45 8.75 1.48 8.54 1.51 8.33 1.57 8.11 1.60
24 18 9.29 1.29 9.07 1.32 8.85 1.34 8.63 1.40 8.41 1.43
AFR
m
3
/h
830
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 3.75 2.15 3.66 2.19 3.57 2.23 3.39 2.32 3.30 2.36
-20 -21 4.79 2.16 4.67 2.20 4.56 2.24 4.33 2.33 4.22 2.38
-15 -16 5.11 2.17 4.99 2.21 4.87 2.25 4.63 2.34 4.50 2.39
-10 -11 5.55 2.13 5.42 2.18 5.29 2.22 5.03 2.31 4.89 2.35
-5 -7 6.00 2.10 5.85 2.14 5.71 2.18 5.42 2.27 5.28 2.31
0 -2 6.17 2.07 6.02 2.11 5.87 2.15 5.58 2.23 5.43 2.28
5 3 7.52 1.88 7.34 1.92 7.16 1.96 6.80 2.04 6.62 2.08
7 6 7.77 1.86 7.58 1.90 7.40 1.94 7.03 2.02 6.84 2.06
10 8 8.58 1.85 8.38 1.89 8.18 1.93 7.77 2.00 7.56 2.04
15 10 8.90 1.64 8.68 1.68 8.47 1.71 8.05 1.78 7.84 1.81
20 15 9.22 1.46 9.00 1.49 8.78 1.52 8.34 1.58 8.12 1.61
24 18 9.55 1.30 9.32 1.33 9.10 1.35 8.64 1.41 8.41 1.43
AFR
m
3
/h
900
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 5.07 2.92 4.95 2.97 4.83 3.03 4.58 3.15 4.46 3.21
-20 -21 5.80 2.93 5.66 2.99 5.52 3.04 5.25 3.16 5.11 3.22
-15 -16 6.53 2.94 6.38 3.00 6.22 3.05 5.91 3.18 5.75 3.24
-10 -11 7.41 2.83 7.24 2.88 7.06 2.93 6.71 3.05 6.53 3.11
-5 -7 8.30 2.71 8.10 2.76 7.90 2.81 7.51 2.92 7.31 2.98
0 -2 8.93 2.60 8.72 2.64 8.51 2.69 8.08 2.80 7.87 2.85
5 3 9.18 2.18 8.96 2.22 8.74 2.27 8.30 2.36 8.09 2.41
7 6 9.34 2.10 9.12 2.15 8.90 2.19 8.45 2.28 8.23 2.32
10 8 9.72 1.97 9.49 2.01 9.26 2.05 8.80 2.13 8.57 2.17
15 10 10.12 1.75 9.88 1.79 9.64 1.82 9.16 1.89 8.91 1.93
20 15 10.53 1.55 10.28 1.59 10.03 1.62 9.53 1.68 9.28 1.72
24 18 10.96 1.38 10.70 1.41 10.44 1.44 9.92 1.50 9.66 1.53
