Fujitsu ASYG12LECA - Page 19

OUTDOOR UNIT
2011.01.25 18
24 Compressor Assy 9317619004
26 3 way Valve Assy 9318254006
30 Pulse Motor Valve Assy 9317216036
29 Solenoid 9970079023
23 Condenser Total Assy 9317192125
31 Expansion Valve Coil 9970103025
27 Muffler 9317398008
28 4 way Valve Assy 9317278034
25 2 way Valve Assy 9318252002
21 Base Assy 9316980013
22 Condenser Assy 9317193016
Ref. Description Part number
21
24
22
25
30
29
27
26
31
23
28
