Fujitsu ASYG12LMCE-R User Manual

En-8
Controlbox
(5)
11.3.3. Installing communication box
(1) Installthecommunicationboxonthemainunitandsecureitwiththeprovided
screwatthelocationshownbelow.
ViewA(Detailview)
Screw
Motorcover
ViewA(Detailview)
(2) Usetheholeonthemotorcoverandsecurethewirefromthecommunicationbox
withtheprovidedcabletie(accessoryforoption).
(Seethefigurebelow)
Cabletie
Cutawaythetipof
thecabletie.
Hole
11.3.4. Installing control box
(1) Setthecontrolboxtowardthebottomsothatittouchesthemotorcoverfromthe
right.
Inserttheprotrudingpartofthemain
unitonthexture(1location)into
thecontrolbox.
Controlbox
• Theinstallationmethodofthecontrolboxisdifferentforeachdestinationcountry.
(Wheninstalling,reusethescrewthatwasremovedin11.3.2. Removing control
box.)
(2) Securethecontrolboxwithascrew.(Usealongscrew.)
(3)
(2)
(3) Fastentheearthwiresoftheheatexchangertogetherasshownintheleftfigure
above.(Useashortscrewhere.)
(4) Hitchthewiresontothefixturesasshownintheovalcirclesbelow.Thenconnect
theconnectorsinthesquarestotheterminalsrespectively.
(Eachterminalshouldformapairwithaconnector.)
CAUTION
•Ensurethattheconnectorisproperlyinserted.
Otherwise,itmayresultinerroneousoperation.
•Becarefulnottodamagethepartsontheboard.
Otherwise,itwillcausemalfunction.
(4)
(5) Fastentheearthwire(green)inthecommunicationboxtogetherwiththeearthwire
(green)ontheboardofthecontrolboxasshowninthefollowingfigure.
(5)
(6) Installthecoverofthecontrolboxontotheinnersideoftheribasfollows.
CAUTION
•Donotcutortuckthewireswiththeelectricalcomponentboxcover.
Anelectricshockmayoccurifthewiresaredamaged.
9333005225_IM_2L.indb 8 10/12/2017 08:49:01
