OUTDOOR UNIT
2011.03.15 18
21
24
22
23
25
29
27
26
30
28
24 Compressor Assy 9317117005
26 3-way Valve Assy 9317174015
29 Pulse Motor Valve Assy 9314557019
4-way Valve Assy 9317110013
-- Solenoid 9970055010
23 Condenser Total Assy 9317089005
30 Expansion Valve Coil 9970095030
27 Muffler 9308625007
28
25 2-way Valve Assy 9315573018
21 Base Assy 9316885066
22 Condenser Assy 9317090001
Ref. Description Part number
