OUTDOOR UNIT
AOYG09LZCAN
AOYG12LZCAN
PARTS
2016.06.09 16
3 Top Panel Assy 9318464023
4 Front Panel Assy 9318463125
2 Protective Net
6
9
Cabinet Left Assy 9318461015
5 Emblem 9319151007
Switch Cover Assy 9318499001
8 Grip 9317588003
7 Cabinet Right Assy 9318462005
10 Propeller Fan 9313808013
Ref. Description Part number
1 Thermistor Holder 9313954031
9332492002
