13
11
OUTDOOR UNIT
AOYG09LZCAN
AOYG12LZCAN
2016.06.09 17
13 Reactor Assy 9900611019
11 Fan Motor 9602724017
Ref. Description Part number
14 Outdoor Thermistor 9900544010
15 Thermistor Assy 9900614027
12
Heater
Holder A
Heater Holder B
12 Heater Unit Assy 9900616014
14
15
