4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢
Models: ASYG18KMTA and ASYG18KMTB
AFR
m
3
/h
980
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 3.18 2.84 0.46 3.48 3.11 0.46 3.59 3.21 0.46 3.82 3.41 0.47 3.93 3.52 0.47 4.19 3.75 0.48 4.47 3.99 0.48
-5 2.98 2.76 0.55 3.26 3.02 0.55 3.36 3.11 0.56 3.58 3.31 0.56 3.69 3.41 0.57 3.93 3.63 0.58 4.19 3.87 0.58
0 2.78 2.68 0.64 3.05 2.93 0.65 3.14 3.02 0.65 3.34 3.21 0.66 3.44 3.31 0.67 3.67 3.52 0.67 3.91 3.76 0.68
5 3.12 2.81 0.44 3.41 3.07 0.44 3.52 3.17 0.45 3.74 3.37 0.45 3.86 3.47 0.45 4.11 3.70 0.46 4.38 3.94 0.46
10 2.95 2.74 0.52 3.23 3.00 0.53 3.33 3.09 0.53 3.54 3.29 0.54 3.65 3.39 0.54 3.88 3.61 0.55 4.14 3.85 0.55
15 3.83 3.11 0.57 4.19 3.40 0.57 4.32 3.51 0.58 4.60 3.73 0.58 4.74 3.84 0.59 5.05 4.09 0.60 5.38 4.37 0.60
20 4.61 3.45 0.93 5.05 3.77 0.94 5.20 3.89 0.95 5.53 4.13 0.96 5.70 4.26 0.97 6.07 4.54 0.98 6.48 4.84 0.99
25 4.49 3.40 1.05 4.92 3.72 1.06 5.07 3.83 1.07 5.39 4.08 1.08 5.56 4.20 1.09 5.92 4.48 1.10 6.31 4.77 1.11
30 4.35 3.34 1.19 4.76 3.65 1.20 4.91 3.76 1.21 5.22 4.00 1.23 5.38 4.13 1.24 5.73 4.40 1.25 6.11 4.69 1.26
35 4.21 3.28 1.33 4.60 3.59 1.35 4.74 3.69 1.36 5.04 3.93 1.38 5.20 4.05 1.39 5.54 4.32 1.40 5.91 4.60 1.42
40 3.92 3.14 1.42 4.29 3.44 1.44 4.42 3.54 1.45 4.70 3.77 1.47 4.85 3.88 1.48 5.17 4.14 1.50 5.51 4.41 1.51
46 3.45 2.91 1.47 3.78 3.18 1.48 3.90 3.28 1.50 4.14 3.48 1.51 4.27 3.59 1.53 4.55 3.83 1.55 4.85 4.08 1.56
¢
Model: ASYG24KMTA and ASYG24KMTB
AFR
m
3
/h
1,170
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 4.34 3.72 0.68 4.75 4.07 0.69 4.90 4.20 0.70 5.21 4.46 0.70 5.37 4.60 0.71 5.72 4.90 0.72 6.10 5.23 0.72
-5 4.07 3.61 0.82 4.46 3.95 0.83 4.59 4.07 0.84 4.88 4.33 0.84 5.03 4.46 0.85 5.36 4.76 0.86 5.72 5.07 0.87
0 3.80 3.50 0.96 4.16 3.83 0.97 4.28 3.95 0.98 4.56 4.20 0.99 4.70 4.33 1.00 5.01 4.61 1.01 5.34 4.92 1.02
5 4.26 3.68 0.65 4.66 4.02 0.66 4.80 4.14 0.67 5.11 4.41 0.67 5.27 4.54 0.68 5.61 4.84 0.69 5.98 5.16 0.69
10 4.03 3.59 0.78 4.41 3.92 0.79 4.54 4.04 0.80 4.83 4.30 0.81 4.98 4.43 0.81 5.30 4.72 0.82 5.65 5.04 0.83
15 5.23 4.07 0.85 5.73 4.45 0.85 5.90 4.59 0.86 6.27 4.88 0.87 6.47 5.03 0.88 6.89 5.36 0.89 7.35 5.71 0.90
20 6.29 4.51 1.39 6.89 4.94 1.41 7.10 5.09 1.42 7.55 5.41 1.44 7.78 5.58 1.45 8.29 5.95 1.46 8.84 6.34 1.48
25 6.14 4.45 1.56 6.71 4.87 1.58 6.92 5.02 1.60 7.36 5.34 1.61 7.59 5.50 1.63 8.08 5.86 1.65 8.62 6.25 1.66
30 5.94 4.37 1.78 6.50 4.78 1.80 6.70 4.93 1.82 7.12 5.24 1.84 7.34 5.40 1.86 7.82 5.75 1.87 8.34 6.13 1.89
35 5.74 4.29 2.00 6.28 4.69 2.02 6.48 4.83 2.04 6.89 5.14 2.06 7.10 5.30 2.08 7.57 5.65 2.10 8.07 6.02 2.12
40 5.36 4.11 2.13 5.86 4.50 2.15 6.04 4.63 2.18 6.42 4.93 2.20 6.62 5.08 2.22 7.05 5.41 2.24 7.52 5.77 2.26
46 4.72 3.80 2.20 5.16 4.16 2.22 5.32 4.29 2.24 5.66 4.56 2.27 5.83 4.70 2.29 6.21 5.01 2.31 6.62 5.34 2.34
- 7 -
