2. Dimensions
2-1. Models: ASYG18KMTA, ASYG18KMTB, ASYG24KMTA, and
ASYG24KMTB
Unit: mm
980 240
280
Outline of indoor unit
for pipe inlet Ø65for pipe inlet Ø65
37
37
400 9041377
7341761 429
115
72
- 4 -
2-1. Models: ASYG18KMTA, ASYG18KMTB, ASYG24KMTA, and ASYG24KMTB 2. Dimensions
WALL MOUNTED
ASYG18, 24KMT
WALL MOUNTED
ASYG18, 24KMT
