WALL MOUNTED ASYG30, 36LMTA
6. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
6-1. Cooling capacity
 Model: ASYG30LMTA
 Model: ASYG36LMTA
AFR
m
3
/h
1,380
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 5.97 5.23 1.30 6.65 5.27 1.32 6.88 5.72 1.33 7.33 5.74 1.34 7.56 6.20 1.35 8.01 6.18 1.36 8.46 6.58 1.38
-10 6.80 5.67 0.98 7.58 5.70 0.99 7.84 6.20 1.00 8.35 6.22 1.01 8.61 6.72 1.01 9.13 6.69 1.02 9.65 7.13 1.03
0 7.04 5.78 1.08 7.84 5.82 1.09 8.11 6.32 1.10 8.64 6.34 1.11 8.91 6.85 1.11 9.44 6.82 1.13 9.98 7.27 1.14
5 6.73 5.63 1.25 7.49 5.67 1.27 7.75 6.16 1.27 8.26 6.18 1.29 8.51 6.67 1.29 9.02 6.65 1.31 9.54 7.08 1.32
10 7.30 5.89 0.95 8.13 5.92 0.97 8.41 6.44 0.97 8.96 6.46 0.98 9.24 6.98 0.99 9.79 6.95 1.00 10.35 7.40 1.01
15 6.99 5.71 1.12 7.78 5.74 1.14 8.05 6.24 1.14 8.58 6.26 1.16 8.85 6.76 1.16 9.38 6.73 1.17 9.91 7.17 1.19
20 6.31 5.01 0.92 7.03 5.04 0.93 7.27 5.48 0.94 7.75 5.50 0.95 7.99 5.94 0.95 8.47 5.92 0.96 8.95 6.30 0.97
25 6.99 5.45 1.44 7.79 5.48 1.46 8.05 5.96 1.47 8.58 5.98 1.48 8.85 6.46 1.49 9.38 6.43 1.51 9.91 6.85 1.52
30 6.84 5.36 2.26 7.62 5.39 2.29 7.88 5.86 2.30 8.40 5.88 2.33 8.66 6.35 2.34 9.18 6.32 2.36 9.70 6.73 2.39
35 6.32 5.19 2.25 7.04 5.22 2.28 7.28 5.68 2.30 7.76 5.69 2.32 8.00 6.15 2.33 8.48 6.13 2.35 8.96 6.53 2.38
40 5.68 4.75 2.51 6.33 4.78 2.55 6.54 5.19 2.56 6.97 5.21 2.59 7.19 5.63 2.60 7.62 5.60 2.63 8.05 5.97 2.65
46 5.17 4.22 2.87 5.76 4.25 2.91 5.96 4.62 2.93 6.35 4.63 2.96 6.55 5.00 2.97 6.94 4.98 3.00 7.34 5.31 3.03
AFR
m
3
/h
1,380
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 5.97 5.23 1.30 6.65 5.27 1.32 6.88 5.72 1.33 7.33 5.74 1.34 7.56 6.20 1.35 8.01 6.18 1.36 8.46 6.58 1.38
-10 6.80 5.67 0.98 7.58 5.70 0.99 7.84 6.20 1.00 8.35 6.22 1.01 8.61 6.72 1.01 9.13 6.69 1.02 9.65 7.13 1.03
0 7.04 5.78 1.08 7.84 5.82 1.09 8.11 6.32 1.10 8.64 6.34 1.11 8.91 6.85 1.11 9.44 6.82 1.13 9.98 7.27 1.14
5 6.73 5.63 1.25 7.49 5.67 1.27 7.75 6.16 1.27 8.26 6.18 1.29 8.51 6.67 1.29 9.02 6.65 1.31 9.54 7.08 1.32
10 7.30 5.89 0.95 8.13 5.92 0.97 8.41 6.44 0.97 8.96 6.46 0.98 9.24 6.98 0.99 9.79 6.95 1.00 10.35 7.40 1.01
15 6.99 5.71 1.12 7.78 5.74 1.14 8.05 6.24 1.14 8.58 6.26 1.16 8.85 6.76 1.16 9.38 6.73 1.17 9.91 7.17 1.19
20 7.81 6.06 1.12 8.70 6.10 1.13 9.00 6.63 1.14 9.60 6.65 1.15 9.89 7.19 1.16 10.49 7.16 1.17 11.08 7.62 1.18
25 8.66 6.60 1.75 9.64 6.63 1.77 9.97 7.21 1.78 10.63 7.24 1.80 10.96 7.81 1.81 11.61 7.78 1.83 12.27 8.29 1.85
30 7.81 6.06 2.74 8.70 6.10 2.78 9.00 6.63 2.80 9.60 6.65 2.82 9.89 7.19 2.84 10.49 7.16 2.87 11.08 7.62 2.89
35 7.43 5.78 3.05 8.27 5.82 3.10 8.55 6.32 3.11 9.12 6.34 3.14 9.40 6.85 3.16 9.96 6.82 3.19 10.53 7.27 3.22
40 6.61 5.54 2.85 7.36 5.58 2.90 7.61 6.06 2.91 8.11 6.08 2.94 8.36 6.57 2.96 8.86 6.54 2.99 9.37 6.97 3.02
46 5.78 5.17 2.87 6.44 5.20 2.91 6.66 5.65 2.93 7.09 5.67 2.96 7.31 6.13 2.97 7.75 6.10 3.00 8.19 6.50 3.03
