OUTDOOR UNIT
AOYG30, 36LMTA
1. Specifications
Type Inverter heat pump
Model name
AOYG30LMTA AOYG36LMTA
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 10.5 13.9
Fan
Airflow rate
Cooling
m
3
/h
3,600 3,800
Heating 3,600 3,800
Type × Q'ty Propeller fan × 1
Motor output W 100
Sound pressure level *1
Cooling
dB(A)
52 55
Heating 55 56
Sound power level
Cooling
dB(A)
67 68
Heating 68 70
Heat exchanger type
Dimensions
(H × W × D)
mm
798 × 900 × 36.4
Fin pitch 1.30
Rows × Stages 2 × 38
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface
treatment
Corrosion resistance (Blue fin)
Compressor
Type × Q'ty Hermetic motor compressor × 1
Motor output W 2,100 2,100
Refrigerant
Type (Global warming potential) R410A (1975)
Charge g 2,100
Refrigerant oil
Type POE (RB68)
Amount
cm
3
800
Enclosure
Material Steel sheet
Color
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
mm
830 × 900 × 330
Gross 970 × 1,050 × 445
Weight
Net
kg
61
Gross 68
Connection pipe
Size
Liquid
mm
Ø 9.52 (Ø 3/8)
Gas Ø 15.88 (Ø 5/8)
Method Flare
Pre-charge length
m
20
Max. length 50
Max. height difference 30
Operation range
Cooling
°C
-15 to 46
Heating -15 to 24
Drain hose
Material LDPE
Size mm Ø 13.0 (I. D.), Ø 16.0 to Ø 16.7 (O. D.)
NOTES:
Specifications are based on the following conditions:
–Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
–Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
–Pipe length: 5 m, Height difference: 0 m.
Protective function might work when using it outside the operation range.
*1: Sound pressure level
–Measured values in manufacturer’s anechoic chamber.
–Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
