Fujitsu AUU18RC

– 17 –
AOU18RC
AOU24RC
2 Fan Cover 9363678000 9363678000
4 Emblem-Rear FUJITSU 9351355005 9351355005
5 Cabinet-A, Painted 9303876015 9303876015
6 Cabinet-C, Painted 9353549013 9353549013
7 Panel (Top), Painted 9355480000 9355480000
9 Cabinet-B, Painted 9303874011 9303874011
10 Noise Insulation-E 313791106305 313791106305
12 Base Assy, Painted 9353452016 9353452016
13 3-Way Valve Assy 9364523002 9364523002
14 2-Way Valve Assy 9365021002 9365021002
15 Dryer 9368114015 9368113025
16 Condenser Assy 9357113012 9363794014
17 U Pipe-Y 313728127102 ––––
18 Suction Pipe 9364138008 9363660005
19-1 Capillary Tube-A 9369086007 9368978006
19-2 Capillary Tube-B 9369087004 9368979003
19-3 Capillary Tube-C –––– 9368980009
20 Discharge Pipe 9357470009 9357470009
21 Discharge Pipe-B 9364303000 9364303000
26 Compressor Cover 9354036000 9354036000
29 Separate Wall 9302475011 9302475011
32-1 Control Box Metal-A 9357137001 9357137001
32-2 Control Box Metal-B 9357138008 9357138008
34 Capacitor (Fan Motor) 9355306010 9355306010
37 Running Capacitor 9356386059
9356386066
38 Capacitor Clamp Metal 313468061808
313468061808
39 Propeller Fan Assy 9300855013 9300855013
41 Fan Motor Assy-Out 9600738139
9600738139
45 Motor Fixing Table Assy 313029311100
313029311100
46 Compressor Assy 9363766004 9363668001
54 Condensing Pipe 313986123207 ––––
55 Special Nut M8 313252257701 313252257701
62 Wire Assy (Shield)-A 9363791006 9363791006
67 Rubber (Vibration-proof) 313659068604 313659068604
107 Rubber Seat-A 313102081406 313102081406
108 Sleeve-A (For Comp.) 313696081700 313696081700
109 Terminal Cover (For Comp.) 9355987004 9355987004
110 Lock Wire (For Comp.) 9355989008 9355989008
111 Terminal Packing (For Comp.) 9355988001 9355988001
128-1 Rubber (Discharge Pipe) 313155086308 313155086308
163-2 Thermo. Spring-A 313728262708 313728262708
187 Clamp No.1219 313361271706 313361271706
196-1 Clamp SKB-3M 312300787605 312300787605
210 Relay 9353611017 9353611017
232 Joint Pipe 9369155000 9369155000
235 Thermistor Assy-Pipe 9701330010 9701330010
236 Controller PCB Assy 9704299017 9704299017
246 Outlet Pipe-A –––– 9363669008
246-1 Outlet Pipe-B Assy –––– 9369088018
259 Muffler 313755083903 313755083903
271 4-Way Valve Rubber 313728251908 313728251908
272 Strainer 9350379019 9300590020
304 Thermostat Fixture-B 313349051500 313349051500
330 Inlet Pipe-A 313986023206 ––––
332 Suction Pipe-E 9369158001 9369158001
333 Accumulator 9303037003 9303037003
335 Outlet Pipe-B –––– 9363670004
338 Motor Fixture Metal 313029297108 313029297108
343-2 Solenoid Coil 9704046017 9704046017
344 4-way Valve 313943302804 9300604017
360 4-way Valve Band 313986251802 313986251802
380 Locking Spacer 313209391403 313209391403
381-4 Spacer 0600118075 0600118075
425 Earth Terminal 9355678001
9355678001
451 Transformer 9900039011
9900039011
519 Check Valve Assy 9368977023 9368977016
549 Thermistor Assy-Out 9357328027
9357328027
620 Inlet Pipe (Cond.) Assy ––––
9363796018
646 Compressor Cover-B 313986355101 313986355101
678 Bracket (Thermistor) 313557406106 313557406106
717 Center Plate 9363776003 9363776003
788 Thermistor Assy-Discharge 9358337011 9358337011
815 Terminal 9358659038 9358659038
826 Condensing Pipe-B 9353580016 ––––
940 Hole Plug 9355891004 9355891004
941 Conduit Plate Metal 9355482004 9355482004
984 U-Pipe (Y) –––– 9305523009
OUTDOOR UNIT
Ref.
No.
Description
Ord.
Q’ty
Part No.
Ref.
No.
Description
Ord.
Q’ty
Part No.
AOU24RCAOU18RC AOU24RCAOU18RC
When you order parts, please make a photocopy of this page
and fill the number of the parts in the Order column.
