Fujitsu AUU18RC

– 18 –
AUU18RC
AUU24RC
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC1 IC PD780058GC-455-8BT 9704385017
IC2 IC NJM7812FA 0100462104
IC3 IC NJM7805FA 0100462081
IC4,5 Xstr Array PA2003GR 0100028041
IC7 IC BR93LC46RF-E2 0100295016
IC8 IC PST600CMTR 0101461120
IC10 IC HI2002 9701384020
IC11 IC BA10358FE2 0101846071
Q1 Xstr 2SC4236 0000164047
Q2 Xstr 2SC1815 0000002011
Q3,4 Xstr DTC124EKA 0000936033
Q5,6 Xstr 2SC2712 0000781053
Q7 Xstr 2SC982 0000005012
D1 Diode D3SB60 0000689045
D2,4 Diode D1FL20U 0000746519
D3 Diode MTZJ5.1B 0000852166
D5,10 Diode 1SR139-600 0000353120
D6 Diode D2FL20U 0000906500
D7 Diode DA226U 0000625036
R1
Res. Cement 5W 3.3 ±10% 0200153148
R2 Res. Cement 2W 1.5 ±5% 0201107119
R3 Res. 1/10W 100 ±5% 0201010501
R4 Res. Metal Film 2W 330k ±5% 0200357133
R5 Res. Metal Oxide 2W 62k ±5% 0201107997
R6
Res. 1/2W 100 ±5% 0200731506
R7 Res. 1/4W 330 ±5% 0200708621
R8,10,14~17, Res. 1/10W 10k ±5% 0201011010
21~24,29~32,
37~39,48,50,
52,55,58~61,
66,69,70,75~
80,91~100
R9,47,65 Res. 1/10W 390 ±5% 0201010648
R18~20,25~28, Res. 1/10W 1k ±5% 0201010747
33~36,40~42,
44,46, 49,51,
71,72,81,RJ1
JM4,7,9 Res. 1/10W 0 0201010013
JM10 Res. 0 0200230016
R43 Res. 1/10W 10k ±1% 0200104010
R45 Res. 1/10W 49.9k ±1% 0200104683
R62 Res. 1/10W 4.7k ±5% 0201010907
R63 Res. 1/10W 15.4k ±1% 0200105567
R64 Res. 1/10W 28k ±1% 0200104447
R88 Res. Metal Oxide 1/2W 120 ±1% 0201105344
C3 Cap. Plastic 0.22 F 0300304099
C5 Cap. Elec. 450V 100 F 0300256060
C6 Cap. Plastic 4700pF 0300269091
C7 Cap. Plastic 50V 0.047 F 0300169339
C8,14 Cap. Elec. 6.3V 100 F 0301197034
C9 Cap. Elec. 25V 1000 F 0301196495
C10,12,16,17, Cap. Ceramic 50V 0.01 F 0301102830
19~31,38,43,
49,CR1,CR6
C11 Cap. Elec. 25V 10 F 0301192312
C13,15,34,37, Cap. Ceramic 25V 0.1 F 0301102885
39,44,45,47
C32,35 Cap. Ceramic 50V 1000pF 0300277096
C54
Cap. Ceramic 0.01 F 0300209158
X1 Ceramic Resonator 9702840013
CSTS0500MG03-T
VA1,2 Varistor TNR10V471K 0000361224
SSR1 Relay G3MC-201PL-VD 9702430016
K4
Relay G5NB-1A 9900007010
T1 Switching Transformer ZFT29B01 9704563019
SW1,4 Switch, Slide DSS803 9701392018
SW2 Switch, Rotary DRS4016-5 9701694013
CN1 Plug, PCB B3P5-VH-B-C 0500011810
CN4
Plug, PCB B2P3-VH-B-Y 0500011827
CN5 Plug, PCB B3P5-VH-B 0500011735
CN6 Plug, PCB B2P3-VH-B-E 0500011759
CN7 Plug, PCB B2B-XAKK-1-A 0501045227
CN8 Plug, PCB B2B-XASK-1-A 0501045012
CN9 Plug, PCB B5P-SHF-1AA 0500006069
CN10 Plug, PCB B5B-XASK-1-A 0501045043
CN14 Plug, PCB B4B-XH-AM 0500005314
CN15 Plug, PCB B3B-XARK-1-A 0501045319
CN17 Plug, PCB B3B-XAKK-1-A 0501045357
Part No. Part No.
[INDOOR UNIT]
CONTROLLER PCB ASSEMBLY (Ref. No.236)
Ref. No. Description
Ord.
Q’ty
C101,102 Cap. Plastic 0.22µF 0300304099
SA101 Arrester RA-362M-V7-F 0600280154
TM101,102
Plug Contact 86028 0500536016
LF101 EMI Filter ELF17N015A 0400197119
F101 Fuse MT3 3.15A-250V 0600239534
E101 Wire w/Terminal L=100 mm GRN 9702313012
W103,104 Wire Assy #18 3P
9704429018
VA101,102 Varistor TNR10V471K 0000361224
Part No.
FILTER PCB ASSEMBLY (Ref. No.875)
When you order parts, please make a photocopy of this page
and fill the number of the parts in the Order column.
