– 19 –
AOU18RC
AOU24RC
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC1 IC PD780024AGK-B67-9ET 9704386014
IC2 IC HU2001 9701651016
IC4 IC NJM7805FA 0100462081
IC5 IC PST600CMTR 0101461120
IC6 Xstr Array PA2003GR 0100028041
IC7 IC BR93LC46RF-E2 0100295016
Q1 Xstr 2SD880 0000001014
Q3,4 Xstr DTC124EKA 0000936033
D1 Diode D2SB20 0000599023
D2 Diode MTZJ15C 0000852203
D3 Diode D1F60 0000208024
LED1,2 Diode SLR-325VC 0000813259
R1,2 Res. Carbon 1/4W 5.6k ±5% 0201038918
R3 Res. Metal Film 6.65k ±1% 0201028766
R7,27~33, CR1, Res. Carbon 1/4W 10k ±5% 0201005019
35~38,40,41
R9,10 Res. Carbon 1/4W 4.7k ±5% 0201038895
R11,12
Res. Metal Film 14k ±1% 0201028612
R13,15~22 Res. Carbon 1/4W 1k ±5% 0201038758
R25
Res. Metal Oxide 1/2W 120 ±5% 0201105344
CJ1~3 Cap. Ceramic 50V 1000pF 0300011096
C1,2,4 Cap. Plastic 0.22 F 0300304099
C7,8 Cap. Elec. 25V 10 F 0301270423
C11 Cap. Elec. 35V 2200 F 0301129066
C12
Cap. Elec. 25V 2200 F 0301269533
C13 Cap. Elec. 25V 100 F 0301270461
C16~20, CR2, Cap. Ceramic 50V 0.01 F 0300013113
CR3
C22~29 Cap. Ceramic 0.1 F 0300988251
X1 Ceramic Resonator EF0EC8384T4 9701261017
K1,2 Relay G5NB-1A 9900007010
K3 Relay JQ1-12V 9701316014
VA1,4,5 Varistor TNR10V471K 0000361224
SA1 Arrester RA-362M-V7-F 0600280154
LF1 EMI Filter ELF17N015A 0400197119
F1 Fuse MT3 3.15A-250V 0600239534
HT1 Heat Sink PUG26-25 9701428014
CN1 Plug, PCB B3P5-VH-B-R 0500011803
CN2 Plug, PCB B2P3-VH-B-R 0500011766
CN3 Plug, PCB B2B-XH-AM 0500005321
CN4 Plug, PCB 53331-0210 0501033019
CN5 Plug, PCB B4P7-VH-B 0500011742
CN9 Plug, PCB 179844-1 0501121013
CN10 Plug, PCB B5P-SHF-1AA 0500006069
CN11
Plug, PCB B2P-VH-B 0500011124
CN12 Plug, PCB B2P-VH-B-C 0500011568
CN13 Plug, PCB B2P-VH-B-R 0500011148
CN15 Plug, PCB B2B-XASK-1-A 0501045012
E1 Wire w/Terminal L=210 GRN 9701325016
Part No. Part No.
[OUTDOOR UNIT]
CONTROLLER PCB ASSEMBLY (Ref. No.236)
and fill the number of the parts in the Order column.
To Next Page
