4-7. CAPACITY TABLE
COOLING
MODELS : AUU42R / AOU42R
AFR 1000
(°FDB)
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0
38.85 26.16 2.21 43.82 26.32 2.24 46.29 28.84 2.26
49.59
30.17 2.29 52.91 31.16 2.31 54.56 34.54 2.33
14
38.32 25.77 2.34 43.22 25.93 2.38 45.66 28.41 2.40
48.92
29.72 2.43 52.19 30.70 2.45 53.82 34.02 2.47
32
36.52 24.64 2.67 41.19 24.79 2.71 43.51 27.16 2.73
46.62
28.41 2.77 49.74 29.35 2.80 51.29 32.52 2.81
41
34.15 23.43 2.86 38.51 23.57 2.91 40.68 25.83 2.94
43.59
27.02 2.97 46.50 27.91 3.00 47.95 30.93 3.02
50
33.43 22.83 3.25 37.71 22.97 3.31 39.84 25.16 3.34
42.68
26.33 3.37 45.53 27.19 3.41 46.95 30.14 3.43
59
40.95 26.97 4.26 46.19 27.13 4.34 48.80 29.73 4.37
52.28
31.10 4.42 55.78 32.12 4.47 57.52 35.60 4.50
67
42.53 28.19 3.89 47.97 28.36 3.96 50.67 31.07 3.99
54.29
32.51 4.04 57.92 33.58 4.08 59.73 37.21 4.10
77
39.64 26.27 4.25 44.71 26.43 4.33 47.23 28.96 4.36
50.60
30.29 4.41 53.98 31.29 4.46 55.67 34.68 4.49
87
36.92 24.84 4.62 41.65 25.00 4.70 43.99 27.39 4.74
47.13
28.65 4.80 50.29 29.59 4.85 51.86 32.80 4.88
95
35.25 23.75 4.81 39.76 23.90 4.89 42.00 26.18 4.93
45.00
27.39 4.99 48.01 28.29 5.05 49.51 31.36 5.07
104
31.20 21.97 4.81 35.19 22.11 4.89 37.17 24.22 4.93
39.83
25.34 4.99 42.49 26.17 5.05 43.82 29.01 5.07
115
19.61 16.63 2.91 22.12 16.73 2.96 23.36 18.33 2.99
25.03
19.18 3.02 26.70 19.81 3.06 27.54 21.96 3.07
67°FWB
SHC: Sensible Heat capacity (kBTU) PI : Power Input (kW)
Outdoor temperature
54°FWB
60°FWB
63°FWB
64°FDB
70°FDB
75°FDB
AFR: Air flow rate(CFM) TC : Total capacity (kBTU)
71°FWB
73°FWB
90°FDB
80°FDB
85°FDB
Indoor temperature
AFR 28.3
(°CDB)
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
-17.78
11.38 7.66 2.21 12.83 7.71 2.24 13.56 8.45 2.26 14.53 8.84 2.29 15.50 9.13 2.31 15.98 10.12 2.33
-10.00
11.22 7.55 2.34 12.66 7.59 2.38 13.37 8.32 2.40 14.33 8.71 2.43 15.29 8.99 2.45 15.76 9.96 2.47
0.00
10.70 7.22 2.67 12.06 7.26 2.71 12.74 7.95 2.73 13.65 8.32 2.77 14.57 8.60 2.80 15.02 9.53 2.81
5.00
10.00 6.86 2.86 11.28 6.90 2.91 11.92 7.57 2.94 12.77 7.92 2.97 13.62 8.17 3.00 14.05 9.06 3.02
10.00
9.79 6.69 3.25 11.05 6.73 3.31 11.67 7.37 3.34 12.50 7.71 3.37 13.34 7.96 3.41 13.75 8.83 3.43
15.00
12.00 7.90 4.26 13.53 7.95 4.34 14.29 8.71 4.37 15.31 9.11 4.42 16.34 9.41 4.47 16.85 10.43 4.50
19.44
12.46 8.26 3.89 14.05 8.31 3.96 14.84 9.10 3.99 15.90 9.52 4.04 16.96 9.83 4.08 17.49 10.90 4.10
25.00
11.61 7.69 4.25 13.09 7.74 4.33 13.83 8.48 4.36 14.82 8.87 4.41 15.81 9.16 4.46 16.30 10.16 4.49
30.56
10.81 7.28 4.62 12.20 7.32 4.70 12.89 8.02 4.74 13.81 8.39 4.80 14.73 8.67 4.85 15.19 9.61 4.88
35.00
10.33 6.96 4.81 11.65 7.00 4.89 12.30 7.67 4.93 13.10 8.02 4.99 14.06 8.29 5.05 14.50 9.18 5.07
40.00
9.14 6.44 4.81 10.31 6.47 4.89 10.89 7.09 4.93 11.67 7.42 4.99 12.45 7.67 5.05 12.83 8.50 5.07
46.11
5.74 4.87 2.91 6.48 4.90 2.96 6.84 5.37 2.99 7.33 5.62 3.02 7.82 5.80 3.06 8.07 6.43 3.07
29.44°CDB
23.89°CDB
21.11°CDB
26.67°CDB
AFR: Air flow rate(m
3
/min)
TC : Total capacity (kW) SHC: Sensible Heat capacity (kW) PI : Power Input (kW)
21.67°CWB
Outdoor temperature
15.56°CWB
17.72°CWB
19.44°CWB
Indoor temperature
17.78°CDB
12.22°CWB
32.22°CDB
22.78°CWB
