CASSETTE TYPE
AUU42R
CASSETTE TYPE
AUU42R
- (04 - 04) -
Display panel
FUNCTIONS
SPECIFICATION
SIZE [H x W x D in. (mm)] 4-23/32 x 4-23/32 x 43/64 (120 x 120 x 17)
WEIGHT oz. (g) 5-21/32 (160)
CABLE LENGTH ft.( m )
POWER ( V )
33 (10)
12
Display
14
13
12
11
10
9
2
1
3
5
4
7
8
6
DAY OFF
DELETE SET
ENERGY
SAVE
SET BACK
DAY
CLOCK ADJUST
SU
MO
TU
WE
TH FR
SA
369
12 15 18 21
THERMO
SENSOR
AM
PM
F
16
15
1718 19
202122 23
SU
MO
TU
WE
TH FR
SA
369
12 15 18 21
AM
PM
F
Set Temperature button
6
1
START/STOP button
Pressed to start and stop operation.
17
Operation mode display
13
Operation lamp
Lights during operation and when the timer is on.
5
Energy save button
Turns the energy efficient mode on and off.
7
Day (DAY OFF) button
14
Timer and clock display
11
Set button
Sets the date, hour, minute and on-off time.
12
8
Set back button
Vertical air flow direction and swing button
Push for two seconds to change the swing mode
Central control display
9
Timer mode (CLOCK ADJUST) button
Set time button
Pessed to select the set back timer.
Master control button
Selects the operating mode(AUTO, HEAT, FAN, COOL, DRY).
4
3
Fan control button
Selects the fan speed (AUTO, LOW, MED, HIGH).
18
Temperature display
16
20
Fan speed display
15
Vertical swing display
21
22
Energy save display
19
Stand by display
Indicates during defrosting operation.
Temporarily cancels of one day timer.
2
10
Delete button
Selects the setting temperature.
Selects the timer mode (OFF TIMER, ON TIMER, WEEKLY TIMER)
pressed select the set back timer.
The schedule of a weekly timer is deleted.
Set the current time.
23
Thermo sensor button
Selects whether the room temperature is detected at the
indoor unit (remote sensor) or the remote controller.
Thermo sensor display
