Fujitsu AUU42R

CASSETTE TYPE AUU42R
CASSETTE TYPE AUU42R
- (04 - 14) -
4-8. CAPACITY COMPENSATION FOR PIPE LENGTH
 AND HEIGHT DIFFERENCE
MODELS : AUU42R / AOU42R
5 m 7.5 m 10 m 20 m 30 m 40 m 50 m 60 m 70 m
16 ft. 25 ft. 33 ft. 66 ft. 98 ft. 131 ft. 164 ft. 197 ft. 230 ft.
30m 98 ft. - - - - 0.907 0.880 0.858 0.837 0.817
20m 66 ft. - - - 0.940 0.907 0.880 0.858 0.837 0.817
10m 33 ft. - - 0.985 0.940 0.907 0.880 0.858 0.837 0.817
7.5m 25 ft. - 1.000 0.985 0.940 0.907 0.880 0.858 0.837 0.817
5m 16 ft. 1.000 1.000 0.985 0.940 0.907 0.880 0.858 0.837 0.817
0m 0 ft. 1.000 1.000 0.985 0.940 0.907 0.880 0.858 0.837 0.817
-5m -16 ft. 0.992 0.992 0.977 0.932 0.900 0.873 0.851 0.830 0.811
-7.5m -25 ft. - 0.988 0.973 0.929 0.896 0.869 0.847 0.827 0.808
-10m -33 ft. - - 0.969 0.925 0.892 0.866 0.844 0.823 0.804
-20m -66 ft. - - - 0.910 0.878 0.852 0.830 0.810 0.791
-30m -98 ft. - - - - 0.863 0.838 0.817 0.797 0.778
COOLING
Outdoor unit
is up-side
PIPE LENGTH
HEIGHT DIFFERENCE
Outdoor unit
is bottom-side
5 m 7.5 m 10 m 20 m 30 m 40 m 50 m 60 m 70 m
16 ft. 25 ft. 33 ft. 66 ft. 98 ft. 131 ft. 164 ft. 197 ft. 230 ft.
30m 98 ft. - - - - 0.923 0.912 0.899 0.886 0.874
20m 66 ft. - - - 0.949 0.933 0.921 0.908 0.896 0.883
10m 33 ft. - - 0.980 0.958 0.942 0.931 0.917 0.905 0.892
7.5m 25 ft. 0.993 0.983 0.961 0.945 0.933 0.920 0.907 0.894
5m 16 ft. 0.995 0.995 0.985 0.963 0.947 0.936 0.922 0.909 0.896
0m 0 ft. 1.000 1.000 0.990 0.968 0.952 0.940 0.927 0.914 0.901
-5m -16 ft. 1.000 1.000 0.990 0.968 0.952 0.940 0.927 0.914 0.901
-7.5m -25 ft. - 1.000 0.990 0.968 0.952 0.940 0.927 0.914 0.901
-10m -33 ft. - - 0.990 0.968 0.952 0.940 0.927 0.914 0.901
-20m -66 ft. - - - 0.968 0.952 0.940 0.927 0.914 0.901
-30m -98 ft. - - - - 0.952 0.940 0.927 0.914 0.901
PIPE LENGTH
Outdoor unit is
bottom-side
Outdoor unit is
up-side
HEIGHT DIFFERENCE
HEATING
