Fujitsu AUU9RLF

382011.03.18
PARTS
OUTDOOR UNIT
2
5
12
13
7
8
1
10
9
11
6
3
4
1 Top Panel Sub Assy
2 Front Panel Sub Assy
3 Service Panel Sub Assy
6 Right Panel Sub Assy
11 Propeller Fan Assy
10 Motor DC Brushless
12 Base Assy
7 Protective Net
9374417049
9374414123
9374415045
9374416172
5 Valve Cover Sub Assy 9374827015
9366378020
9602843015
9 Motor Bracket Sub Assy 9374418060
8 Thermo Holder 9375211011
9374166305
13 Compressor Plate Assy 9375221058
9375381028
4 Emblem Rear 9351355005
-- Drain Assy 9303029015
-- Drain Cap 313166024302
Ref. Description Part number
