Fujitsu AUXG07KVLA - Dimensions; Compact Cassette Type

3. Dimensions
3-1. Compact cassette type
¢
Models: AUXG07KVLA, AUXG09KVLA, AUXG12KVLA, and
AUXG14KVLA
Unit: mm
285 285
Ceiling
114
B
View A
570: Indoor unit
370
540
Hanging bolt position
a: Ceiling openings
530
530
Hanging bolt position
Drain hose
A
215
19
30
123
30
262
183
Control Box
146
40
C
620
620
IR receiver
Grid type grille
View B
View C
114
a: Ceiling openings
Cassette grille (Option [Grid type]) mm 580 to 610
- 13 -
3-1. Compact cassette type 3. Dimensions
2-UNIT MULTI-SPLIT TYPE 2-UNIT MULTI-SPLIT TYPE
