7-2. Model: AOYG18KBTA2
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢ Indoor unit: 7,000 Btu/h
Cooling
Pipe length
m 2.5 5 10 15 20
Height difference H (m)
Indoor unit is higher than outdoor
unit *1
15 — — — 0.940 0.914
10 — — 0.973 0.948 0.921
5 — 0.991 0.980 0.955 0.928
2.5 0.993 0.993 0.982 0.957 0.930
0 1.000 1.000 0.989 0.963 0.936
Indoor unit is lower than outdoor
unit *2
-2.5 1.000 1.000 0.989 0.963 0.936
-5 — 1.000 0.989 0.963 0.936
-10 — — 0.989 0.963 0.936
-15 — — — 0.963 0.936
Heating
Pipe length
m 2.5 5 10 15 20
Height difference H (m)
Indoor unit is higher than outdoor
unit *1
15 — — — 0.942 0.925
10 — — 0.959 0.942 0.925
5 — 1.000 0.959 0.942 0.925
2.5 0.990 1.000 0.959 0.942 0.925
0 0.990 1.000 0.959 0.942 0.925
Indoor unit is lower than outdoor
unit *2
-2.5 0.986 0.996 0.955 0.938 0.921
-5 — 0.994 0.953 0.936 0.919
-10 — — 0.949 0.933 0.916
-15 — — — 0.928 0.911
¢ Indoor unit: 9,000 Btu/h
Cooling
Pipe length
m 2.5 5 10 15 20
Height difference H (m)
Indoor unit is higher than outdoor
unit *1
15 — — — 0.928 0.898
10 — — 0.966 0.936 0.905
5 — 0.991 0.972 0.942 0.911
2.5 0.993 0.993 0.974 0.944 0.913
0 1.000 1.000 0.981 0.951 0.920
Indoor unit is lower than outdoor
unit *2
-2.5 1.000 1.000 0.981 0.951 0.920
-5 — 1.000 0.981 0.951 0.920
-10 — — 0.981 0.951 0.920
-15 — — — 0.951 0.920
Heating
Pipe length
m 2.5 5 10 15 20
Height difference H (m)
Indoor unit is higher than outdoor
unit *1
15 — — — 0.942 0.924
10 — — 0.959 0.942 0.924
5 — 1.000 0.959 0.942 0.924
2.5 0.990 1.000 0.959 0.942 0.924
0 0.990 1.000 0.959 0.942 0.924
Indoor unit is lower than outdoor
unit *2
-2.5 0.986 0.996 0.955 0.938 0.920
-5 — 0.994 0.953 0.936 0.918
-10 — — 0.949 0.932 0.915
-15 — — — 0.928 0.910
- 281 -
7-2. Model: AOYG18KBTA2 7. Capacity compensation rate for pipe length and height difference
OUTDOOR UNIT
AOYG14-18KBTA2
OUTDOOR UNIT
AOYG14-18KBTA2
