Fujitsu AUXG07KVLA Design & Technical Manual

6-2. Cooling capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AOYG14KBTA2
Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
21
-10.0
3.60 0.63 4.10 0.64 4.30 0.64 4.60 0.65 4.90 0.66 5.10 0.66
0.0 3.60 0.28 4.10 0.28 4.30 0.28 4.60 0.29 4.90 0.29 5.10 0.29
5.0 3.60 0.45 4.10 0.46 4.30 0.46 4.60 0.47 4.90 0.47 5.10 0.47
10.0 3.60 0.38 4.10 0.38 4.30 0.38 4.60 0.39 4.90 0.39 5.10 0.40
15.0 3.60 0.50 4.10 0.51 4.30 0.51 4.60 0.52 4.90 0.52 5.10 0.53
20.0 3.60 0.59 4.10 0.60 4.30 0.61 4.60 0.62 4.90 0.62 5.10 0.63
25.0 3.60 0.76 4.10 0.78 4.30 0.78 4.60 0.79 4.90 0.80 5.10 0.81
30.0 3.60 0.91 4.10 0.93 4.30 0.94 4.60 0.95 4.90 0.96 5.10 0.96
35.0 3.60 1.21 4.10 1.23 4.30 1.24 4.60 1.25 4.90 1.26 5.10 1.27
40.0 3.10 1.00 3.50 1.02 3.70 1.03 4.00 1.04 4.30 1.05 4.40 1.06
46.0 2.70 1.01 3.10 1.03 3.20 1.04 3.50 1.05 3.70 1.06 3.80 1.07
19
-10.0
3.60 0.63 4.10 0.64 4.30 0.64 4.60 0.65 4.90 0.66 5.10 0.66
0.0 3.60 0.28 4.10 0.28 4.30 0.28 4.60 0.29 4.90 0.29 5.10 0.29
5.0 3.60 0.45 4.10 0.46 4.30 0.46 4.60 0.47 4.90 0.47 5.10 0.47
10.0 3.60 0.38 4.10 0.38 4.30 0.38 4.60 0.39 4.90 0.39 5.10 0.40
15.0 3.60 0.50 4.10 0.51 4.30 0.51 4.60 0.52 4.90 0.52 5.10 0.53
20.0 3.60 0.59 4.10 0.60 4.30 0.61 4.60 0.62 4.90 0.62 5.10 0.63
25.0 3.60 0.76 4.10 0.78 4.30 0.78 4.60 0.79 4.90 0.80 5.10 0.81
30.0 3.60 0.91 4.10 0.93 4.30 0.94 4.60 0.95 4.90 0.96 5.10 0.96
35.0 3.60 1.21 4.10 1.23 4.30 1.24 4.60 1.25 4.90 1.26 5.10 1.27
40.0 3.10 1.00 3.50 1.02 3.70 1.03 4.00 1.04 4.30 1.05 4.40 1.06
46.0 2.70 1.01 3.10 1.03 3.20 1.04 3.50 1.05 3.70 1.06 3.80 1.07
18
-10.0
3.60 0.63 4.10 0.64 4.30 0.64 4.60 0.65 4.90 0.66 5.10 0.66
0.0 3.60 0.28 4.10 0.28 4.30 0.28 4.60 0.29 4.90 0.29 5.10 0.29
5.0 3.60 0.45 4.10 0.46 4.30 0.46 4.60 0.47 4.90 0.47 5.10 0.47
10.0 3.60 0.38 4.10 0.38 4.30 0.38 4.60 0.39 4.90 0.39 5.10 0.40
15.0 3.60 0.50 4.10 0.51 4.30 0.51 4.60 0.52 4.90 0.52 5.10 0.53
20.0 3.60 0.59 4.10 0.60 4.30 0.61 4.60 0.62 4.90 0.62 5.10 0.63
25.0 3.60 0.76 4.10 0.78 4.30 0.78 4.60 0.79 4.90 0.80 5.10 0.81
30.0 3.60 0.91 4.10 0.93 4.30 0.94 4.60 0.95 4.90 0.96 5.10 0.96
35.0 3.60 1.21 4.10 1.23 4.30 1.24 4.60 1.25 4.90 1.26 5.10 1.27
40.0 3.10 1.00 3.50 1.02 3.70 1.03 4.00 1.04 4.30 1.05 4.40 1.06
46.0 2.70 1.01 3.10 1.03 3.20 1.04 3.50 1.05 3.70 1.06 3.80 1.07
16
-10.0
3.60 0.63 4.10 0.64 4.30 0.64 4.60 0.65 4.90 0.66 5.10 0.66
0.0 3.60 0.28 4.10 0.28 4.30 0.28 4.60 0.29 4.90 0.29 5.10 0.29
5.0 3.60 0.45 4.10 0.46 4.30 0.46 4.60 0.47 4.90 0.47 5.10 0.47
10.0 3.60 0.38 4.10 0.38 4.30 0.38 4.60 0.39 4.90 0.39 5.10 0.40
15.0 3.60 0.50 4.10 0.51 4.30 0.51 4.60 0.52 4.90 0.52 5.10 0.53
20.0 3.60 0.59 4.10 0.60 4.30 0.61 4.60 0.62 4.90 0.62 5.10 0.63
25.0 3.60 0.76 4.10 0.78 4.30 0.78 4.60 0.79 4.90 0.80 5.10 0.81
30.0 3.60 0.91 4.10 0.93 4.30 0.94 4.60 0.95 4.90 0.96 5.10 0.96
35.0 3.60 1.21 4.10 1.23 4.30 1.24 4.60 1.25 4.90 1.26 5.10 1.27
40.0 3.10 1.00 3.50 1.02 3.70 1.03 4.00 1.04 4.30 1.05 4.40 1.06
46.0 2.70 1.01 3.10 1.03 3.20 1.04 3.50 1.05 3.70 1.06 3.80 1.07
14
-10.0
3.60 0.63 4.10 0.64 4.30 0.64 4.60 0.65 4.90 0.66 5.10 0.66
0.0 3.60 0.28 4.10 0.28 4.30 0.28 4.60 0.29 4.90 0.29 5.10 0.29
5.0 3.60 0.45 4.10 0.46 4.30 0.46 4.60 0.47 4.90 0.47 5.10 0.47
10.0 3.60 0.38 4.10 0.38 4.30 0.38 4.60 0.39 4.90 0.39 5.10 0.40
15.0 3.60 0.50 4.10 0.51 4.30 0.51 4.60 0.52 4.90 0.52 5.10 0.53
20.0 3.60 0.59 4.10 0.60 4.30 0.61 4.60 0.62 4.90 0.62 5.10 0.63
25.0 3.60 0.76 4.10 0.78 4.30 0.78 4.60 0.79 4.90 0.80 5.10 0.81
30.0 3.60 0.91 4.10 0.93 4.30 0.94 4.60 0.95 4.90 0.96 5.10 0.96
35.0 3.60 1.21 4.10 1.23 4.30 1.24 4.60 1.25 4.90 1.26 5.10 1.27
40.0 3.10 1.00 3.50 1.02 3.70 1.03 4.00 1.04 4.30 1.05 4.40 1.06
46.0 2.70 1.01 3.10 1.03 3.20 1.04 3.50 1.05 3.70 1.06 3.80 1.07
NOTES:
• TC: Total Capacity (kW), IP: Input Power (kW)
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• 2 or more indoor units should be connected.
• The total ability of connected indoor unit is from 14,000 Btu/h up to 21,000 Btu/h.
• Input in the table are calculated based on the maximum indoor unit input combinations.
