Fujitsu AUXG07KVLA Design & Technical Manual

¢
Model: AOYG18KBTA2

Cooling
Combination of in-
door unit
Rated capacity for
each indoor unit
(kW)
Total capacity
(kW)
Input power (kW)
EER
(W/W)
Seasonal data
Unit
Total
Unit
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy efficien-
cy class
1 2 1 2
7 7 14 2.00 2.00 1.7 4.00 5.0 0.25 0.92 1.23 4.35 4.0 8.8 A+++
7 9 16 2.00 2.50 1.7 4.50 5.7 0.25 1.07 1.45 4.22 4.5 8.7 A+++
7 12 19 1.84 3.16 1.7 5.00 5.8 0.25 1.24 1.55 4.03 5.0 8.6 A+++
7 14 21 1.67 3.33 1.7 5.00 5.8 0.25 1.24 1.55 4.03 5.0 8.6 A+++
9 9 18 2.50 2.50 1.7 5.00 5.8 0.25 1.24 1.55 4.03 5.0 8.6 A+++
9 12 21 2.14 2.86 1.7 5.00 5.8 0.25 1.24 1.55 4.03 5.0 8.6 A+++
9 14 23 1.96 3.04 1.7 5.00 5.8 0.25 1.24 1.55 4.03 5.0 8.6 A+++
12 12 24 2.50 2.50 1.7 5.00 5.8 0.25 1.24 1.55 4.03 5.0 8.6 A+++
12 14 26 2.31 2.69 1.7 5.00 5.8 0.25 1.24 1.55 4.03 5.0 8.6 A+++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h
• The above is the value for connecting with KG models in wall mounted type.
• 2 or more indoor units should be connected.
• Cooling: Indoor temperature of 27 °CDB/19 °CWB and outdoor temperature of 35 °CDB.
• Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• The total ability of connected indoor units is from 14,000 Btu/h up to 26,000 Btu/h.

Heating
Combination of indoor
unit
Rated capacity for
each indoor unit
(kW)
Total capacity
(kW)
Input power (kW)
COP
(W/W)
Seasonal data
Unit
Total
Unit
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency class
1 2 1 2
7 7 14 2.40 2.40 1.70 4.80 5.60 0.25 0.99 1.35 4.85 3.8 4.7 A++
7 9 16 2.40 3.00 1.70 5.40 6.40 0.25 1.15 1.60 4.70 4.0 4.7 A++
7 12 19 2.06 3.54 1.70 5.60 7.00 0.25 1.22 1.80 4.59 4.2 4.7 A++
7 14 21 1.87 3.73 1.70 5.60 7.00 0.25 1.22 1.80 4.59 4.2 4.7 A++
9 9 18 2.80 2.80 1.70 5.60 7.00 0.25 1.22 1.80 4.59 4.2 4.7 A++
9 12 21 2.40 3.20 1.70 5.60 7.00 0.25 1.22 1.80 4.59 4.2 4.7 A++
9 14 23 2.19 3.41 1.70 5.60 7.00 0.25 1.22 1.80 4.59 4.2 4.7 A++
12 12 24 2.80 2.80 1.70 5.60 7.00 0.25 1.22 1.80 4.59 4.2 4.7 A++
12 14 26 2.58 3.02 1.70 5.60 7.00 0.25 1.22 1.80 4.59 4.2 4.7 A++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h
• The above is the value for connecting with KG models in wall mounted type.
• 2 or more indoor units should be connected.
• Heating: Indoor temperature of 20 °CDB, and outdoor temperature of 7 °CDB/6 °CWB.
• Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• The total ability of connected indoor units is from 14,000 Btu/h up to 26,000 Btu/h.
- 244 -
6-1. Combinations 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2

Fujitsu AUXG07KVLA Specifications
