Fujitsu AUXG07KVLA - Page 254


Slim duct type
Model: ARXG07KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
0.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
5.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
10.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
15.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
20.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
25.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
30.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
35.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
40.0 1.57 0.94 1.77 1.07 1.87 1.23 2.00 1.39 2.13 1.52 2.20 1.74
46.0 1.36 0.71 1.54 0.81 1.62 0.93 1.74 1.05 1.86 1.15 1.91 1.31
Model: ARXG09KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
0.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
5.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
10.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
15.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
20.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
25.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
30.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
35.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
40.0 1.76 1.02 1.99 1.16 2.10 1.34 2.25 1.50 2.40 1.64 2.48 1.88
46.0 1.53 0.77 1.73 0.88 1.83 1.01 1.96 1.14 2.09 1.24 2.16 1.43
Model: ARXG12KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.28 1.54 2.58 1.75 2.72 2.02 2.91 2.27 3.11 2.48 3.21 2.84
0.0 2.28 1.54 2.58 1.75 2.72 2.02 2.91 2.27 3.11 2.48 3.21 2.84
5.0 2.28 1.54 2.58 1.75 2.72 2.02 2.91 2.27 3.11 2.48 3.21 2.84
10.0 2.28 1.54 2.58 1.75 2.72 2.02 2.91 2.27 3.11 2.48 3.21 2.84
15.0 2.28 1.54 2.58 1.75 2.72 2.02 2.91 2.27 3.11 2.48 3.21 2.84
20.0 2.28 1.54 2.58 1.75 2.72 2.02 2.91 2.27 3.11 2.48 3.21 2.84
25.0 2.28 1.54 2.58 1.75 2.72 2.02 2.91 2.27 3.11 2.48 3.21 2.84
30.0 2.28 1.54 2.58 1.75 2.72 2.02 2.91 2.27 3.11 2.48 3.21 2.84
35.0 2.28 1.54 2.58 1.75 2.72 2.02 2.91 2.27 3.11 2.48 3.21 2.84
40.0 1.98 1.16 2.24 1.32 2.36 1.52 2.53 1.71 2.70 1.87 2.78 2.14
46.0 1.72 0.88 1.95 1.00 2.05 1.15 2.20 1.29 2.35 1.42 2.42 1.62
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
